Mô tả sản phẩm: JBE ADIV-FSD-001
| Model No. | ADIV-TSD-001 | ADIV-TSM-001 | ADIV-TSU-001 | ADIV-TLD-001 | ADIV-FSD-001 |
| System | PAL / NTSC | ||||
| Image Sensor | 1/3" Sony Super HAD | 1/3" LG | 1/4" Sony Super HAD | ||
| DSP+CCD(P) | CXD3142R+633 | CXD3142R+633 | NVP4140+633 | CXD3142R+329 | CXD3142R+643 |
| DSP+CCD(N) | CXD3142R+632 | CXD3142R+632 | NVP4140+632 | CXD3142R+325 | CXD3142R+642 |
| Pixel | PAL:752*582;NTSC:768*494 | PAL: 500 x 582;NTSC: 510 x 492 | |||
| Video output | 1.0Vp-p, 75II Composite, BNC x 1 | ||||
| TVL | 420TVL | 450TVL | 520TVL | 420TVL | 420TVL |
| S/N Ratio | >=48dB | ||||
| Illumination | 0.8 Lux/F1.2 | 0.5 Lux/F1.2 | 0.3 Lux/F1.2 | 1.0 Lux/F1.2 | 1.0 Lux/F1.2 |
| ES | 1/50 - 1/10,0000S | ||||
| White Balance | Auto Tracking White Balance | ||||
| Gamma Ratio | >=0.45 | ||||
| OSD | No | No | Yes | No | No |
| Lens Mount | Built-in 3.6mm/6mm Fix Lens | ||||
| Working Temp. | Outdoor: -10C to +50C | ||||
| Humidity | 0 to 95% RH (non-condensing) | ||||
| Sync System | 2:1 interlace internal Sync. | ||||
| Voltage Input | 12V DC | ||||
| Package Size | 10CM*10CM*9CM | ||||
| Weight | Appro x 0.5kgs | ||||
High Resolution Series
| Model No. | ADIV-TCT-001 | ADIV-TST-001 | ADIV-TCH-001 | ADIV-TSH-001 | ADIV-TSH-001A |
| System | PAL / NTSC | ||||
| Image Sensor | 1/3" CMOS(IR CUT) | 1/3" Sony Super HAD | 1/3" CMOS(IR CUT) | 1/3" Sony Effio-E | 1/3" Sony Super HAD |
| DSP+CCD(P) | PC1089 | NVP2040E+639 | OV139 | CXD4140G+673 | NVP2090+811 |
| DSP+CCD(N) | PC1089 | NVP2040E+638 | OV139 | CXD4140G+672 | NVP2090+810 |
| Pixel | PAL:752*582;NTSC:768*494 | PAL:1024*596;NTSC:1028*508 | |||
| Video Output | 1.0Vp-p, 75II Composite, BNC x 1 | ||||
| TVL | 600TVL | 600TVL | 700TVL | 700TVL | 700TVL |
| S/N Ratio | >=48dB | >=52dB | |||
| Illumination | 0.001 Lux/F1.2 | 0.03 Lux/F1.2 | 0.001 Lux/F1.2 | 0.001 Lux/F1.2 | 0.001Lux/F1.2 |
| ES | 1/50 - 1/10,0000S | ||||
| White Balance | Auto Tracking White Balance | ||||
| Gamma Ratio | >=0.45 | ||||
| OSD | No | Yes | No | Yes | Yes |
| Lens Mount | Built-in 3.6mm/6mm Fix Lens | ||||
| Working Temp. | Outdoor: -10C to +50C | ||||
| Humidity | 0 to 95% RH (non-condensing) | ||||
| Sync System | 2:1 interlace internal Sync. | ||||
| Voltage Input | 12V DC | ||||
| Package Size | 10CM*10CM*9CM | ||||
| Weight | Appro x 0.5kgs | ||||
