Mô tả sản phẩm: Tấm dẫn điện dùng cho máy cắt dây Sodick
| Power Feed Contact | |||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application |
 |
S001 | 3080316 | Φ18X10 | Upper | AP150. AW. BF. EPOC~W series Guide unit 83 / AWT type |
 |
S002 | 3080314 | Φ18X14 | Lower | AP150. AW. BF. EPOC~W series Guide unit 83.84 / AWT type |
 |
S003S | 3080318 | 16X10 | Upper | EPOC~W. G. GW. GOW series Guide unit 84 / AWT type Material : Silver tungsten |
 |
S003T | 3080318 | 16X10 | Upper | EPOC~W. G. GW. GOW series Guide unit 84 / AWT type Material : Cermet |
 |
S004S | 3080324 | 14X11X12 | Upper | AW. AP150. BF. EPOC series Guide unit 85-3 / AWT type Material : Silver tungsten |
 |
S005LS | 3080307 | 12.5X14X11.7 | Upper | AW. AP150. BF. EPOC series Guide unit 85-2.3 / Manual type Material : Silver tungsten |
 |
S005RS | 3080308 | 12.5X14X11.7 | Upper | AW. AP150. BF. EPOC series Guide unit 85-2.3 / Manual type Material : Silver tungsten |
 |
S005LT | 3080307 | 12.5X14X11.7 | Upper | AW. AP150. BF. EPOC series Guide unit 85-2.3 / Manual type Material : Cermet |
 |
S005RT | 3080308 | 12.5X14X11.7 | Upper | AW. AP150. BF. EPOC series Guide unit 85-2.3 / Manual type Material : Cermet |
 |
S006S | 3080311 | 12.5X19X11.6 | Lower | AW. BF. EPOC~W. GO. GW series Guide unit 85-2.3 type Material : Silver tungsten |
 |
S008S | 3080320 | Φ12X20.6 | Common | AP150 series Guide unit KM-3 type Material : Silver tungsten |
 |
S009S | 3080301 | Φ10X8X30 | Common | A. AP. AQ. AW. EPOC series Guide unit 86-1 type Material : Silver tungsten |
 |
S010 | 3085936 3080972 3084592 |
4.8X40X20 | Common | A. AP. AQ. AW. EPOC series Guide unit 87-3 type |
 |
S010G | 3085936 3080972 3084592 |
4.8X40X20 | Common | A. AP. AQ. AW. EPOC series Guide unit 87-3 type TiN coated - Gold color |
 |
S010L | 3085936 3080972 3084592 |
4.8X40X20 | Common | A. AP. AQ. AW. EPOC series Guide unit 87-3 type TiAIN coated - Grey color |
