Mô tả sản phẩm: Nắp chụp nước dùng cho máy cắt dây Sodick
| Flushing Nozzle | |||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application |
| S200 | 3081591 | Common | AW330.453.654W. BF250.275. EPOC-W Guide unit 85-2 type |
||
 |
S201 | 3081594 | Φ5 | Common | AW330.453.654W. BF250.275. EPOC-W Guide unit 85-2 type |
 |
S202 | 3082085 | Common | AW330.454. BF275. EPOC300 series Guide unit 85-2 / Manual type |
|
 |
S202A | 3080030 | Common | AW330.454. BF275. EPOC300 series Guide unit 85-2 / Manual type |
|
 |
S202B | 3080593 | Common | AW330.454. BF275. EPOC300 series Guide unit 85-2 / Manual type |
|
 |
S202C | 3080358 | Φ5 | Common | AW330.454. BF275. EPOC300 series Guide unit 85-2 / Manual type |
 |
S202S | 3080639 | Common | AW330.454. BF275. EPOC300 series Guide unit 85-2 / Manual type |
|
 |
S203 | 3082056 | Φ6 Φ10 |
Common | AP150. PGW150 series Guide unit KM-3 type |
 |
S204 | 3082055 | Φ5 | Common | AP. AW150 series Guide unit KM-1 type |
 |
S205 | Φ10 | Common | AP. AW150 series Guide unit KM-1 type |
|
 |
S206 | Φ5 | Common | AP. AW150 series Guide unit KM-1 type |
|
 |
S207 | 3082997 3082998 3081604 3081605 3081606 3081868 |
Φ3 (G3) Φ4 (G4) Φ6 (C) Φ8 (H1) Φ10 (H2) Φ12 (T2) |
Upper | AQ. A. AP. EPOC. PGW. BF. JL. EXC series Guide unit 86-2 / Manual type Guide unit 90-1 / AWT type |
 |
S207-1 | Φ3 Φ4 Φ6 Φ8 Φ10 |
Upper | AQ. A. EPOC. AP. PGW. BF. JL. EXC series Guide unit 85. 86-2. 90-1. 97 / AWTtype |
|
 |
S207L | 3081682 3081684 3081689 3082396 Special1 Special2 |
Φ6.0x6.5-LN1 Φ6.0x11.5-LN2 Φ6.0x16.5-LN3 Φ6.0x26.5 Φ10x11.5 Φ10x16.5 |
Upper | AQ. A. EPOC. AP. PGW. BF. JL. EXC series Guide unit 85. 86-2. 90-1. 97 / AWTtype |
 |
S208 | 3081674 | Φ3, 4, 6 Φ10, 12 |
Common | A350.500. AW330. 454 series Without O ring |
 |
S209 | 3082156 3082128 3082207 3081674 3081675 3081676 3081867 |
Φ2 -E2 Φ3 -E3 Φ4 -E4 Φ6 -A Φ8 -B Φ10-H1 Φ12 -T1 |
Common | A. EPOC. AP. PGW. BF. JL. EXC series Guide unit 87-3 type Lower for AWT, Common for manual type With O ring |
 |
S209-1 | 3086396 3086746 3086742 |
Φ6 Φ10 Φ12 |
Lower | AP200. 450L series Guide unit 90-3 / AWT type Without O ring |
 |
S209-2 | 3085336 |
Φ6 | Lower | AQ. A. AP300. 550 series Guide unit 90-5 / AWT type Without O ring |
 |
S209W | 3086386 --- 3086443 3086486 |
Φ6 Φ8 Φ10 Φ12 |
Lower | AQ. A. AP300. 550 series Guide unit 87-3 / AWT type Without O ring |
 |
S209L | 3085338 3085339 3085340 3085341 3085342 3085343 |
Φ6 -4mm Φ4 - 10mm Φ4 -15mm Φ6 -20mm Φ10 -25mm Φ12 -50mm |
Common | A. AP. AQ. BF. EXC. EPOC. JL. PGW series Lower for guide unit 85.97 / AWT type Common nozzle A for Manual type OD=20mm Ref. 3081677(Φ6) 3081678(Φ10) |
 |
S210 | 3082603 |
Φ3 | Lower | A280L. ---L series Lehmann type / AWT type Nozzle F with ID3 |
 |
S210-1 | 3082603 |
Φ12 | Lower | A280L.---Lseries Lehmann type / AWT type Nozzle F |
