| Print |
Print Method |
Dye-Sublimation (Color), Thermal Transfer (Mono) |
| Print Speed |
Mono : 4 sec/ pc, Single Color : 26 sec/pc, |
| Dual Color: 35 sec/pc |
| Print Mode |
Single & Dual Side Print |
| TPH |
Resolution: 300dpi(11.8dpm) |
| Pulsed Life : 1 x 108 Pulses / Abrasion : 50Km |
| Color |
16.7 Million Color |
| Ribbon |
KO-500 prints/roll, YMCKO-200 prints/roll, |
| YMCKOK-167 prints/roll |
| K, Silverl, Gold, Red, Blue, White- 1000 prints/roll |
| Protection by RFID Tag |
| Card |
Card Types |
PVC, Composite PVC |
| Card Thickness |
0.2mm ~ 1.2mm |
| Card Format |
ISO CR-80-ISO 7810 (53.98mm W X 85.60 mm L / 3.375" X 2.125") |
| Encoding |
MS Card |
ISO7811(track 1,2,3), Coercivity : Hi-Co/Lo-Co |
| (option) |
Contact(IC) Card |
ISO7816, EMV, K-cash, Contact Landing Type |
|
Mobile Chip Card |
Default, ISO 7816 |
|
Contactless(RF) Card |
Mifare, ISO 14443 A,B, ISO 15693 |
| Network |
Ethernet(TCP/IP) |
Built-in Ethernet(10/100 Mbps) |
| (option) |
| Scanner |
Resolution |
Dual Side Color : 600 dpi |
| (option) |
Speed |
4 sec/ pc ( scanner speed only) |
| Other |
Barcode |
Code 39, code 128 B & C with & Without check digit |
| 2 of 5 interleaved |
| UPC-A, EAN 8 & EAN 13 |
| PDF-417 2D bar code and other symbols can be printed via |
| Window drivers |
| Fonts |
True Type fonts via Windows drivers |
| CPU |
32 bit processor |
| RAM |
16 MB |
| SAM |
PLCC 1 (Extra-2 sockets), Sim 4 sockets |
| I/F Port |
USB2.0, RS-232C, Network(option) |
| Printer Driver |
Windows 2000, XP, Vista |
| Feeding Method |
Single Feeding |
Single-card feeding |
| Auto Feeding |
Hopper - 100 cards |
|
| Stacker - 70 cards |
| Step Motor Driven |
|
| Motor |
0 ~ 50℃, 20 ~ 90% RH |
|
| Temperature |
Operating Temp. |
-25 ~ 70℃ |
|
| Storage Temp. |
Input: 100V ~ 250V, 50/60Hz, Output: DC 24V |
|
| Power |
Adaptor |
Single : 403(L) x 202(H) x 192 (W) |
|
| Size |
Dimension(mm) |
Dual : 471(L) x 202(H) x 192 (W) |
|
| Single : 5.5 kg / Dual 6.5 kg |
|
| Net Weight |
|
|
