| Product Specifications | |
| Function | Specification |
| FrequencyRange | UHF Band：794~806MHz / Frequency range depents on the ragulations in different countries. |
| Oscillator | Quartz lock contrdled. |
| Frequency Bandwidth | 12MHz |
| Receiving Mode | Dual Channel, NON-Diversity |
| Frequency Stability | ± 0.005% |
| Modulation Mode | FM |
| LED indicator | To Indicate battery life |
| AF Response | 60Hz~16000Hz |
| RF Sensitivity | ＜-95dBm for 30dB S/N Radio |
| DeviationRange | ± 55KHz |
| Audio Output | XLR/ unbalanced output 6.3 Ø jack |
| RF Power Output | 10dBm |
| Signal to Noise Ratio | >107dB(A) |
| Overall System T.H.D | < 0.8% |
| Power Supply | DC12~18V |
| Receiver Dimensions | 430 x 160 x 44mm |
| Receiver Weight | 1.2kg |
| Battery | 1.5V (AA) x 2 |
| Microphone Dimensions | Ø55mm x 242mm |
