| 1.1 | Manufacturer | EP | ||||
| 1.2 | Model designation | CQD16RVH | CQD16RV | CQD16RVF | ||
| 1.3 | Drive unit | Battery | Battery | Battery | ||
| 1.4 | Operator type | Rider seated | Rider seated | Rider seated | ||
| 1.5 | Load capacity | Q | kg | 1600 | 1600 | 1600 |
| 1.7 | Load center | c | mm | 600 | 600 | 600 |
| Weights | ||||||
| 2.1 | Service weight (Incl. battery) | kg | 3020 | 3070 | 3070 | |
| Wheels, Chassis | ||||||
| 3.1 | Tyre type | PU/ PU | PU/ PU | PU/ PU | ||
| 3.5 | Wheels, number front/ rear (x=drive wheels) | 2/1x | 2/1x | 2/1x | ||
| Dimensions | ||||||
| 4.1 | Mast/ fork carriage tilt, forward/ backward | α/β | ° | 3/6 | 3/6 | 3/6 |
| 4.2 | Height, mast lowered | h1 | mm | 2130(2S3m) | 2130(2S3m) | 2130(2S3m) |
| 4.3 | Free lift | h2 | mm | 120(2S3m) | 120(2S3m) | 120(2S3m) |
| 4.4 | Lift height | h3 | mm | 3000(2S3m) | 3000(2S3m) | 3000(2S3m) |
| 4.5 | Height, mast extended | h4 | mm | 4065(2S3m) | 4065(2S3m) | 4065(2S3m) |
| 4.7 | Height of overhead guard (cabin) | h6 | mm | 2200 | 2200 | 2200 |
| 4.19 | Overall length | l1 | mm | 2302 | 2302 | 2302 |
| 4.21 | Overall width | b1 | mm | 1270 | 1270 | 1270 |
| 4.26 | Width between straddle arms | b4 | mm | 917 | 917 | 917 |
| 4.27 | Outside fork width, minimum/ maximum | b5 | mm | 200-760 | 200-760 | 200-760 |
| 4.28 | Reach distance | l4 | mm | 526 | 526 | 526 |
| 4.33 | Aisle width, 1000×1200 pallet crossways | Ast | mm | 2580 | 2580 | 2580 |
| 4.34 | Aisle width, 800×1200 pallet lengthways | Ast | mm | 2780 | 2780 | 2780 |
| 4.35 | Outer turning radius | Wa | mm | 1705 | 1705 | 1705 |
| Performance | ||||||
| 5.1 | Travel speed, laden/ unladen | km/h | 10/11 | |||
| 5.2 | Lifting speed, laden/ unladen | mm/s | 300/450 | |||
| 5.4 | Reach speed，laden/unladen | mm/s | 180 | |||
| 5.7 | Maximum gradeability, laden/ unladen S2 5 min. | % | 10/15 | |||
| 5.1 | Service brake | hydrauli/electric | ||||
| Drive | ||||||
| 6.1 | Drive motor rating S2 60 min. | kW | 6.5 | |||
| 6.2 | Lift motor rating at S3 15% | kW | 8.6 | 8.6 | ||
| Lift system | DC | AC | ||||
| 6.3 | Control valve | manual | electric | |||
| 6.4 | Battery voltage/ rated capacity (5h) | Ah/V | 420/48 | 500/48 | 500/48 | |
| 6.5 | Battery weight (with box) | kg | 745 | 796 | 796 | |
| Others | ||||||
| 8.1 | Type of drive control | AC ZAPI | AC ZAPI | AC ZAPI | ||
| steering | Electirc power steering | |||||
