LOW RATE TO 628 LPM (166 GPM)
MAX PRESSURE = 8.6 BAR (125 PSIG)
WETTED HOUSINGS
(Liquid Chambers and Manifolds)
| Material | Ship Wt |
| Aluminum | 37 kg (81 lbs) |
| Ductile Iron | 57 kg (125 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
| Center Block | Aluminum |
| Air Chambers | Aluminum |
| Air Valve | Aluminum |
MAXIMUM SUCTION LIFT CAPABILITY
7.9 m (26.1') dry, 9.3 m (30.6') wet
MAXIMUM DIAMETER SOLIDS
51 mm (2")
ELASTOMER OPTIONS
| Material | Temperature Limits |
| Buna-N® | -12.2 (+10) to +65.6 (+150) °C (F°) |
| Neoprene | -17.8 (+0) to +93.3 (+200) °C (F°) |
