| •Lifting Capacity (top layer): 300 Kg |
| •First Layer Speed: 12 m/min |
| •Top Layer Speed: 18 m/min |
| •Motor Rating IP44: 1.0 HP x 4 poles |
| •Maximum Lifting Height: 29 m |
| •Wire Rope: 6 mm x 30 m |
| •Drum Barrel Diamete: 74 mm |
| •Drum Flange Dia: 154 mm |
| •Distance between Flanges: 153mm |
| Note: |
| Above performance ratings are based on 50 Hz supply. (60 Hz motor available as option resulting in a reduction of lifting capacities by 20% and a speed increase of 20%) 1. All ratings are based on the top layer. For each layer reduction on the drum pulling capacity is increased by 10% 2. Use a snatch block for double line operation, to increase line pull by approximately 85% |
|
PULLING LOAD CAPACITY FOR VARIOUS INCLINES in kg
|
||||||||||||||
|
||||||||||||||
| A gradient of 10% is a rise of one meter in ten meters. The pulling capacities are based on a free pulling load and 15% has been allowed for friction (specific applications will vary) |
