| Type | Min. sensing object ø25 mm ø0.984 in type (20 mm 0.787 in beam pitch) |
|||
| Model No. | Pigtailed type | SF4C-H8-J05 | SF4C-H12-J05 | SF4C-H16-J05 |
| Cable type | SF4C-H8 | SF4C-H12 | SF4C-H16 | |
| No. of beam channels | 8 | 12 | 16 | |
| Protective height | 160 mm 6.299 in |
240 mm 9.449 in |
320 mm 12.598 in |
|
| Current consumption |
Large multipurpose indicator lights off |
Emitter: 70 mA or less Receiver: 85 mA or less |
Emitter: 70 mA or less Receiver: 90 mA or less |
|
| Large multipurpose indicator lights up |
Emitter: 120 mA or less Receiver: 135 mA or less |
Emitter: 120 mA or less Receiver: 140 mA or less |
||
| PFHd | 1.66 x 10-9 | 1.90 x 10-9 | 2.10 x 10-9 | |
| MTTFd | 100 years or more | |||
| Net weight (Total of emitter and receiver) |
Pigtailed type |
240 g approx. | 300 g approx. | 360 g approx. |
| Cable type | 630 g approx. | 700 g approx. | 760 g approx. | |
