| Type | DC 2-wire type | ||||
| Front sensing | Top sensing | ||||
| Model No. | GL- 8FUx10 |
GL- 8FUBx10 |
GL- 8HUx10 |
GL- 8HUBx10 |
|
| Different frequency | GL- 8FUIx10 |
GL- 8FUIBx10 |
GL- 8HUIx10 |
GL- 8HUIBx10 |
|
| Max. operation distance (Note 2) | 2.5 mm 0.098 in ± 20 % | ||||
| Stable sensing range (Note 2) | 0 to 1.8 mm 0 to 0.071 in | ||||
| Standard sensing object | Iron sheet 15 x 15 x t 1 mm 0.591 x 0.591 x t 0.039 in |
||||
| Hysteresis | 20 % or less of operation distance (with standard sensing object) |
||||
| Supply voltage | 12 to 24 V DC ± 10 % Ripple P-P 10 % or less | ||||
| Current consumption | 0.8 mA or less (Note 3) | ||||
| Output | Non-contact DC 2-wire type - Load current: 3 to 70 mA (Note 5) - Residual voltage: 3 V or less (Note 6) |
||||
| Utilization category | DC-12 or DC-13 | ||||
| Output operation | Normally open | Normally closed | Normally open | Normally closed | |
| Short-circuit protection | Incorporated | ||||
| Max. response frequency | 1kHz | ||||
| Operation indicator | Orange LED (lights up when the output is ON) | ||||
| Pollution degree | 3 (Industrial environment) | ||||
| Protection | IP67 (IEC) | ||||
| Ambient temperature | -25 to +70 ℃ -13 to +158 ℉, Storage: -30 to +80 ℃ -22 to +176 ℉ |
||||
| Ambient humidity | 35 to 95 % RH, Storage: 35 to 95 % RH | ||||
| EMC | EN 60947-5-2 | ||||
| Voltage withstandability | 1,000 V AC for one min. between all supply terminals connected together and enclosure | ||||
| Insulation resistance | 50 MΩ, or more, with 250 V DC megger between all supply terminals connected together and enclosure | ||||
| Vibration resistance | 10 to 55 Hz frequency, 1.5 mm 0.059 in amplitude in X, Y and Z directions for two hours each | ||||
| Shock resistance | 1,000 m/s2 acceleration (100 G approx.) in X, Y and Z directions for three times each | ||||
| Sensing range variation |
Temperature characteristics | Over ambient temperature range -25 to +70 ℃ -13 to +158 ℉ : within +10 -15 % of sensing range at +20 ℃ +68 ℉ |
|||
| Voltage characteristics | Within ±2 % for ±10 % fluctuation of the supply voltage | ||||
| Material | Enclosure: Polyalylate | ||||
| Cable | 0.15 mm2 2-core cabtyre cable, 1 m 3.281 ft long | ||||
| Cable extension | Extension up to total 50 m 164.042 ft is possible with 0.3 mm2, or more, cable. | ||||
| Weight | Net weight : 12 g approx. | ||||
