| Type | NPN output | PNP output | |||
| Model No. (Note 2) |
Front sensing | GX- F15A(I) |
GX- F15B(I) |
GX- F15A(I)-P |
GX- F15B(I)-P |
| Top sensing | GX- H15A(I) |
GX- H15B(I) |
GX- H15A(I)-P |
GX- H15B(I)-P |
|
| Max. operation distance (Note 3) | 5 mm 0.197 in ± 8 % | ||||
| Stable sensing range (Note 3) | 0 to 4.2 mm 0 to 0.165 in | ||||
| Standard sensing object | Iron sheet 20 x 20 x t 1 mm 0.7874 x 0.7874 x t 0.039 in | ||||
| Hysteresis | 20 % or less of operation distance (with standard sensing object) |
||||
| Repeatability | Along sensing axis, perpendicular to sensing axis: 0.04 mm 0.0016 in or less | ||||
| Supply voltage | 12 to 24 V DC+10/-15% Ripple P-P 10 % or less | ||||
| Current consumption | 15 mA or less | ||||
| Output | NPN open-collector transistor - Maximum sink current: 100 mA - Applied voltage: 30 V DC or less (between output and 0 V) - Residual voltage: 2 V or less (at 100 mA sink current) |
PNP open-collector transistor - Maximum source current: 100 mA - Applied voltage: 30 V DC or less(between output and +V) - Residual voltage: 2 V or less (at 100 mA source current) |
|||
| Output operation | Normally open | Normally closed | Normally open | Normally closed | |
| Max. response frequency | 250 Hz | ||||
| Operation indicator | Orange LED (lights up when the output is ON) |
||||
| Protection | IP68 (IEC), IP68g (JEM)(Note 4, 5) | ||||
| Ambient temperature | -25 to +70 ℃ -13 to +158 ℉, Storage: - 40 to +85 ℃ - 40 to +185 ℉ | ||||
| Ambient humidity | 45 to 85 % RH, Storage: 35 to 95 % RH | ||||
| Sensing range variation |
Temperature characteristics |
Over ambient temperature range -25 to +70 ℃ -13 to +158℉: Within ±8 % of sensing range at +23℃ +73.4 ℉. | |||
| Voltage characteristics |
Within ±2 % for +10/-15 % fluctuation of the supply voltage | ||||
| Material | Enclosure: PBT, Indicator part: Polyester | ||||
| Cable | 0.15 mm2 3-core oil, heat and cold resistant cabtyre cable, 1 m 3.281 ft long | ||||
| Net weight | 20 g approx. | ||||
