| AC A | 0~600.0/1000A |±2.0%rdg±5dgt (50/60Hz) |±3.5%rdg±5dgt (40~500Hz) |
| DC A | 0~600.0/1000A |±1.5%rdg±5dgt |
| AC V | 6/60/600V Auto Ranging |±1.5%rdg±4dgt (50/60Hz) |±3.5%rdg±5dgt (40~400Hz) |
| DC V | 600m/6/60/600V Auto Ranging |±1.0%rdg±3dgt |
| Ω | 600/6k/60k/600k/6M/60MΩ (Auto Ranging) |±1%rdg±5dgt (600~6M) / ±5%rdg±8dgt (60M) |
| Continuity buzzer | Buzzer Sounds at 100Ω |
| Frequency/DUTY | 10/100/1k/10kHz (Auto Ranging) / 0.1~99.9% |
| Temperature | -50ºC ~ +300ºC (With the use of Temperature probe 8216) |
| Conductor Size | Ø40mm |
| Withstand Voltage | 6880V AC for 5 seconds |
| Safety Standard | IEC 61010-1 CAT.IV 600V, IEC61010-031, IEC61010-2-032, IEC61326 |
| Power Source | R03(1.5V)(AAA) × 2 |
| Dimensions | 254(L) × 82(W) × 36(D)mm |
| Weight | 310g |
| Accessories | 7066 (Test Lead) 9094 (Carrying Case) Instruction Manual |
| Option | 8216 (Temperature Probe) |
