| Technical specifications | ||||||
| T Y P E | MOS211A | MOS211B | MOS211C | MOS211D | MOS211E | MOS211F |
| Ordering number | 02838A | 02838B | 02838C | 02838D | 02838E | 02838F |
| Optical power | 6 dBm (4 mW) | 8 dBm (6 mW) | 10 dBm (10 mW) | 12 dBm (16 mW | 13 dBm (20 mW) | 14 dBm (25 mW |
| Type of laser | DFB | |||||
| Modulation type | direct | |||||
| Optical wave length | 1310 ± 10 nm | |||||
| RF frequency range | 47-862 MHz | |||||
| RF input level | 75...90 dBµV | |||||
| Relative intensity noise RIN | < -155 dB/Hz | |||||
| Intermodulation distortion CSO* | > 62 dB | |||||
| Intermodulation distortion CTB* | > 65 dB | |||||
| Carrier/noise ratio C/N* | > 51 dB | |||||
| AGC range | > 51 dB | |||||
| Gain adjustment | 15 dB by 0.5 dB step | |||||
| Slope adjustment control |
10 dB by 0.5 dB step | |||||
| Power consumption | 187-250V~ 50 Hz 10 W | |||||
| Operating temperature range | 0o÷ + 50oC | |||||
| Dimensions/Weight (packed) | 485x58.5x171 mm/3.8 kg | |||||
