| SPECIFICATION |
| •Lifting Capacity (top layer): 10,000 kg |
| •Lifting Speed: Option: 9 ~ 13 m/min |
| •Motor: Option: 30 HP x 6 poles |
| •Lifting height: 190 m |
| •Wire Rope: 22.4 mm x 200 m |
| Note: |
| Above performance ratings are based on 50 Hz supply. (60 Hz motor available as option resulting in a reduction of lifting capacities by 20% and a speed increase of 20%) 1. All ratings are based on the top layer. For each layer reduction on the drum pulling capacity is increased by 10% 2. Use a snatch block for double line operation, to increase line pull by approximately 85% |
| DIMENSIONS (mm) |
 |
| STANDARD ACCESSORIES |
| •Wire rope w/safety hook |
| •Switch cord 1.25 mm x 3C x 3 m |
| •Power lead 3.5 mmx 4C x 0.3 m |
| •Pendant Switch K61 |
| •Base Plate |
| OPTIONAL ACCESSORIES |
| •Pendant control K-61B assembly |
| PACKAGE |
| •Winch Weight: 2800 kg |
| •Gross Weight: 2900 kg |
