Mô tả sản phẩm: Server FUJITSU Server PRIMERGY RX2560 M1 E5-2660 v3 (Intel Xeon E5-2660 v3 2.60GHz, RAM 8GB, HDD 1TB SATA, PS 748W)
Technical details
| Chipset | Intel® C612 |
|---|---|
| Mainboard type | D3289 |
| Product Type | Dual Socket Rack Server |
| Processor | Intel® Xeon® processor E5-2600 v3 product family-based platform |
| Memory | 8 GB - 1536 GB, DIMM (DDR4) |
| Memory protection | Advanced ECC, Memory Scrubbing, SDDC (Chipkill™), Rank sparing memory support, Memory Mirroring support |
| Drives (optional) | DVD-ROM, half height, SATA I DVD Super Multi, half height, SATA I DVD Super Multi, slimline, SATA I LTO4HH Ultrium, 120 MB/s, 800 GB, SAS 6Gb/s LTO5HH Ultrium, 140 MB/s, 1,500 GB, SAS 6Gb/s DVD supermulti, ultraslim, SATA I Blu-ray Disc™ Triple Writer, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB , USB 3.0 LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/s |
| PCI-Express 3.0 x4 | 4 x Full height optional; Slot 5+6 (CPU 1, riser card); Slot 11+12 (CPU 2, riser card), 252mm length |
| PCI-Express 3.0 x8 | 5 x Full height ; Slot 1 (CPU1, modular RAID, 167mm), Slot 2 (CPU1, 167mm), opt. Slot 4 (CPU1, opt. riser card, 252mm); opt. Slot 8 (CPU2, 167mm), opt. Slot 10 (CPU2, opt. riser card, 252mm) |
| PCI-Express 3.0 x16 | 3 x Full height ; Slot 3 (CPU1), Slot 8+9 (CPU2), 167mm lenght; ! please be aware, optional riser cards occupy Slot 3 / 9 |
| Slot Notes | Slot 1: PCIe Gen3 x8 slot is dedicated for the modular RAID Controller. up to 5 PCIe Gen3 slots are supported with the first processor, up to 10 PCIe Gen3 slots are supported with two processors. Onboard slots (Slot1, 2, 3 & 7, 8, 9) support card lenght of up to 167mm; Slots on the optional riser cards (4, 5, 6; 10, 11, 12) support card lenght of up to 252mm |
| Accessible drive bays | 3 x 5.25/1.6-inch |
| Optional accessible drives | up to 3x 5.25/1.6-inch bay for accessible devices (depending on the amount of storage drive bays) All possible options described in relevant system configurator. |
| Storage drive bays | 3.5-inch or 2.5-inch hot-plug SAS/SATA max. 12x 3.5" hot plug HDD + opt.2x2.5" NON hot plug HDD/SSD or max. 32x 2.5" hot plug HDD/SSD |
| Storage drives | HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SATA, 6 Gb/s, 2 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SATA, 6 Gb/s, 3 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SATA, 6 Gb/s, 4 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SATA, 6 Gb/s, 500 GB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SAS, 6 Gb/s, 1 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SAS, 6 Gb/s, 2 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SAS, 6 Gb/s, 3 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical HDD SAS, 6 Gb/s, 4 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical SSD SATA, 6 Gb/s, 100 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise SSD SATA, 6 Gb/s, 200 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise SSD SATA, 6 Gb/s, 400 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise SSD SATA, 6 Gb/s, 800 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise HDD SATA, 6 Gb/s, 250 GB, 7,200 rpm, non hot plug, 2.5-inch, business critical SSD SAS, 12 Gb/s, 1.6 TB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise SSD SAS, 12 Gb/s, 200 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise SSD SAS, 12 Gb/s, 400 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise SSD SAS, 12 Gb/s, 800 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise DOM SATA, 6 Gb/s, 128 GB, non hot plug, enterprise, 345TBW (Seq. write) DOM SATA, 6 Gb/s, 32 GB, non hot plug, enterprise, 86TBW (Seq. write) DOM SATA, 6 Gb/s, 64 GB, non hot plug, enterprise, 172TBW (Seq. write) SSD SATA, 6 Gb/s, 120 GB, Read-Intensive Endurance, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years) SSD SATA, 6 Gb/s, 240 GB, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years) SSD SATA, 6 Gb/s, 480 GB, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years) SSD SATA, 6 Gb/s, 800 GB, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years) HDD SAS, 12 Gb/s, 300 GB, 15,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 12 Gb/s, 450 GB, 15,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 12 Gb/s, 600 GB, 15,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 6 Gb/s, 1.2 TB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 6 Gb/s, 300 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 6 Gb/s, 600 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 6 Gb/s, 900 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 12 Gb/s, 1.2 TB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 12 Gb/s, 1.8 TB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 12 Gb/s, 450 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 12 Gb/s, 600 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 12 Gb/s, 900 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise HDD SAS, 6 Gb/s, 500 GB, 7,200 rpm, non hot plug, 2.5-inch, business critical SSD SATA, 6 Gb/s, 120 GB, Read-Intensive Endurance, non hot plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years) |
| RAID Controller | RAID Ctrl., SAS/SATA 12 Gbit/s, Fujitsu PRAID CP400i, 8 ports int. RAID level: 0, 1, 10, 5, 50 No BBU support RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, Fujitsu PRAID EP400i, 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU based on LSI SAS3108 RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, Fujitsu PRAID EP420i, 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB, Optional FBU based on LSI SAS3108 |
| I/O controller onboard | Intel® C612, 1 x SATA connector for optical drive (ODD), 1x SATA connector for SATA-DOM additional RAID controller options are described under Components RAID controller DynamicLoM based on Emulex XE100 series Integrated Remote Management Controller (iRMC S4, 256 MB attached memory incl. graphics controller), IPMI 2.0 compatible |
| Trusted Platform Module (TPM) | Infineon / separate module; TCG V1.2 compliant (option) |
| Power supply configuration | 1x hot-plug power supply or 2 x hot-plug power supply for redundancy |
| Active power (max. configuration) | 748 W |
| Weight | up to 35.5 kg |
| Rack (W x D x H) | 482.6 mm (Bezel) / 448 mm (Body) x 736 x 177 mm |
| Mounting Depth Rack | 721 mm |
| Server Management | Server Management |
| Standard | ServerView Suite - Deploy SV Installation Manager SV Scripting Toolkit, ServerView Suite - Control Operations Manager incl. PDA and ASR & R (Prefailure and Analysis; Automatic Server Recovery and Restart) Agents and CIM Providers System Monitor RAID Manager Capacity Management Power Management Storage Support, ServerView Suite - Maintain Remote Management (iRMC in combination with Intel® Node Manager) Update Management (BIOS, Firmware, Windows Drives and SV Agents) Performance Measurement Asset Management Online Diagnostics, ServerView Suite - Integrate Integration packs e.g. for Microsoft System Center, VMware vCenter, Nagios, HP SIM and others |
| Option | ServerView Suite - Maintain iRMC Advanced Pack incl. Advanced Video Redirection (AVR), video capturing and Virtual Media, ServerView Suite - Integrate Integration pack for Fujitsu ManageNow® solution, ServerView Suite - Dynamize Virtual-IO Manager (VIOM) |
| Special features | No compromise Rack Server offering maximum levels of performance, availability and expandability. Ideal for performance hungry applications, virtualization solutions and storage demanding scenarios |
| Warranty period | 3 years |
| Warranty type | Onsite warranty |
| Service Lifecycle | 5 years after end of product life |
| Service Weblink | http://www.fujitsu.com/fts/products/product-support-services/ |
