Mô tả sản phẩm: Savvytech SV-CN5276D
| Image | ||
| Image Sensor | 1/3″ Sony CCD | |
| Horizontal Resolution | 700 TVL | |
| Lens | ||
| Focal Length | 2.8-12mm Lens | |
| Focus | Manual | |
| Zoom | Manual | |
| ICR | Yes | |
| Electrical | ||
| Video System | NTSC | |
| Video Scanning Type |
2:1 Interlace |
|
| Sync. System | Internal | |
| S/N Ratio | > 52dB (AGC off) | |
| Min. Illumination | Color:> 0.01 Lux, B&W:0 Lux(IR On) | |
| Video Output | 1 BNC, 1.0 Vp-p, 75 Ohm Composite | |
| Function | ||
| Electronic Shutter | NTSC: 1/60 ~ 1/100,000,
PAL: 1/50 ~ 1/100,000 |
|
| White Balance | ATW | |
| BLC | Auto | |
| Auto Gain Control | Auto | |
| UTC | Yes | |
| Motion Detection | 4 Zones | |
| Privacy Mask | 4 Zones | |
| DNR | 3D DNR | |
| Mirror | Yes | |
| Infrared LED | ||
| Infrared Red Lamps | 48 pcs IR LEDs | |
| IR Distance | 130ft (40m) | |
| Power | ||
| Input Voltage | DC 12V 500mA & AC24V 3A | |
| Power Consumption | < 2W (LED OFF) / < 6W (LED ON) | |
| Environment | ||
| Weather Protection | IP 66 weather-proof | |
| Vandal Protection | Vandal-resistant | |
| Operating Temperature | 14°F ~ 122 °F (-10℃ ~ 50 ℃) | |
| Storage Temperature | 4°F ~ 122 °F (-20℃ ~ 50 ℃) | |
| Humidity | RH90% Max. (Non-condensing) | |
| Mechanical | ||
| Chasis Material | Aluminum housing | |
| Color | White/Beige/Black | |
| Product Net Weight | 2.3 lb (1030g) | |
| Product Dimension | 240mm x 127mm x 89mm | |
| Accessories | ||
| Bracket | Yes | |
| Screw | 3 | |
| Expansion Tube | 3 | |
| Screwdriver | 1 | |
| Manual | 1 | |
