Mô tả sản phẩm: Nature NVM-102P/N
|
Model No.
|
NVM-102P/N
|
||
|
Name
|
Color Mini Camera
|
||
|
Camera
|
Image Sensor
|
1/3" Interlaced-Scan CCD
|
|
|
Signal System
|
PAL/NTSC
|
||
|
Effective Pixels
|
PAL:976(H)×582(V) NTSC:976(H)×494(V)
|
||
|
Horizontal Resolution
|
600TVL
|
||
|
Min. Illumination
|
Color:0.1Lux @(F1.2,AGC ON),0.01Lux@ (F1.2,AGC ON, Sens-up×512)
|
||
|
Shutter Time
|
N:1/60~1/10,000sec; P:1/50~1/10,000sec
|
||
|
Lens
|
Type
|
Fixed
|
|
|
Focal Length
|
2.8/3.7/6/8mm Optional ; standard 3.7mm
|
||
|
Aperture
|
F2.0
|
||
|
Lens
|
M12
|
||
|
Sync. System
|
Internal/Line Lock
|
||
|
Menu Control
|
Video Output
|
1Vp-p Composite Output(75Ω/BNC)
|
|
|
S/N Ratio
|
>50dB(AGC OFF)
|
||
|
AGC
|
Off/Auto
|
||
|
White Balance
|
Auto Tracking/Auto Control/Manual
|
||
|
Privacy Mask
|
On/Off,1~8 Areas
|
||
|
Motion Detection
|
On/Off
|
||
|
BLC
|
Off/BLC/High BLC
|
||
|
Language
|
Chinese/English
|
||
|
General
|
Function Setting
|
DNR, Sharpness, Brightness, Low Illumination Adjustment,
Saturation, Mirror, Motion Detection
|
|
|
Working Temperature
& Humidity
|
—10℃~60℃，Humidity <90%（non-condensing）
|
||
|
Power Supply
|
DC12V±10%
|
||
|
Power Consumption
|
1.9W
|
||
|
Dimension (mm)
|
25(W)X25(H)mmX15(D)mm
|
||
|
Weight
|
145g
|
||
