Mô tả sản phẩm: Qik MES1-FH42
| Model | MES1-FH42 | MES1-AB42 | MES1-AN50 | MES1-GI60 | MES1-BN65 | |||
| Image Sensor | 1/4" COLOR SHARP CCD |
1/3" COLOR SONY Super HAD Ⅱ CCD |
1/3" COLOR SONY Super HAD Ⅱ CCD |
1/3" COLOR SHARP CCD |
1/3" COLOR SONY Super HADⅡ CCD |
|||
| TV System | PAL/NTSC | |||||||
| Image Resolution | PAL:528(H)×512(V), NTSC:512(H)×492(V) |
PAL:500(H)×582(V), NTSC:510(H)×492(V) |
PAL:500(H)×582(V), NTSC:510(H)×492(V) |
PAL:752(H)×582(V), NTSC:768(H)×494(V) |
PAL:752(H)×582(V), NTSC:768(H)×494(V) |
|||
| Horizontal Resolution | 420TVL | 420TVL | 500TVL | 600TVL | 650TVL | |||
| Digital to Analog | 12Bit | 9Bit | 10Bit | 10Bit | 10Bit | |||
| Minimum illuminator | 0.0005LUX/F2.0 | |||||||
| S/N Ratio | ≥48dB | ≥58dB | ||||||
| AES | 1/50-1/60,000sec(PAL),1/60-1/60,000sec(NTSC) | |||||||
| WDR | — | — | — | — | D-WDR | |||
| N/R | — | — | — | — | 3D | |||
| OSD | — | — | — | — | OSD | |||
| White Balance | Auto | |||||||
| Gain Control | Auto | |||||||
| BLC | Auto | |||||||
| Gamma Adjusting | 0.45 | |||||||
| synchronization System | Internal Synchronization | |||||||
| Video Output | 1.0Vp-p,75Ω | |||||||
| Voltage | DC12V ±10% | |||||||
| Operating Enviroment | -20℃~60℃ / 10% ~ 95%RH | |||||||
| Demension | 75mm x 74mm | |||||||
| Weight | 320g | |||||||
