Vantr VR1CS70

Description:

Waterproof IR Bullet Camera

TV System:

PAL/NTSC

Lens:

CS Lens 4mm/F1.6(1.3 Megapixel)

IR LED:

1 pc, IR range: 50M


Image Sensor:

1/3" Color SONY CCD

Horizontal Resolution:

700 TV Lines

Effective Pixels:

PAL: 976(H)×582(V); NTSC: 976(H)×494(V)

Min. Illumination:

0.001Lux/F1.2

S/N Ratio:

≥52dB(AGC OFF)

Shutter Speed:

Auto: PAL 1/50-1/100,000Sec; NTSC 1/60-1/100,000Sec

Gamma Correction:

0.45

Sync System:

Internal

Scanning System:

PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec

Video Output:

Composite Signal (1.0Vp-p, 75Ω)

Features

OSD:

CN, EN, FR, DE, JP, ES, PT, RU

Day&Night:

Color/ B&W

AGC:

Auto

White Balance:

Auto

Exposure:

Auto

BLC:

YES

Private Area Mask:

YES

Image Adjustment:

YES

WDR:

DWDR

Noise Reduction:

2D NR

Demist:

N/A

Strong Light Reduction:

N/A

Sense-up

N/A

UTC Support:

N/A

Ingress Protection:

IP66

General

Working Temperature and Humidity:

'-10℃ ~ +60℃，Humidity＜90%(no condensation)

Power Supply:

'DC12V±10%, 800mA

Demension:

126mm(L) x 75mm(H) x 68mm(D)

Weight:

800g
