Mô tả sản phẩm: TRC TC32EV
| Model | TC3216(MID-RES) | TC3416(HI-RES) | TC3616(VHI-RES) |
| Image device | 1/3" color CCD sensor interline | ||
| Effective picture elements | NTSC 510(H) x 492(V) PAL 500(H) x 582(V) |
NTSC 768(H) x 494(V) PAL 752(H) x 582(V) |
NTSC 768(H) x 494(V) PAL 752(H) x 582(V) |
| Scanning system | 2:1 Interlace | ||
| Synchronizing system | Internal | ||
| Horizontal resolution | More than 380 TV lines | More than 480 TV lines | More than 540 TV lines |
| Electronic shutter control | Auto-Electronic Shutter (1/60~1/100000 sec)NTSC; (1/50~1/100000 sec)PAL | ||
| Gamma | 0.45 | ||
| Minimum illumination | 1.0 Lux/F1.8 IR on : 0 Lux | 1.2 Lux/F1.8 IR on : 0 Lux | 1.2 Lux/F1.8 IR on : 0 Lux |
| Video output level | 1Vp-p / 75 | ||
| Video S/N ratio | 48dB(AGC off) | ||
| White balance | Auto(2500K~9500K) | ||
| Storage temperature | -30°C~80°C | ||
| Operating temperature | -10°C~50°C | ||
| Power requirements | DC 12V, AC 90~260V | ||
| Power consumption(DC12V) | 620mA | 650mA | 680mA |
| AGC function | Auto | ||
| Emitting wavelength of LED | 850nm | ||
| Emitting angle of LED | 40° | ||
| Number of IR LED | 63 PCS | ||
| Dimensions | 230 (L) X 108 (W) X 95 (H) mm | ||
| Weight | 1300g | ||
| Lens | STD: 8.0mm / F2.0 ; Option: 4.3mm / 6.0mm / 12.0mm / 16.0mm | ||
