Approximate

Dimensions:

23.5 cm (H) x 29 cm (W) x 20.5 cm (D);
9.25 in (H) x 11.4 in (W) x 8 in (D)

Approximate Weight

(without battery):

5.66 kg; 12.5 lbs

Standard Operator Position:

Within one meter (3 feet) of the device

Power:

Rechargeable Lithium Ion battery; AC power using a protectively grounded outlet

Waveform:

Biphasic Truncated Exponential; waveform parameters adjusted as a function of patient impedance

Shock Delivery:

Via multifunction electrode pads or paddles

Shock Series:

Configurable energy escalation in a series

Leads Off Sensing and PCI

Sensing for Pads/Paddles:

Apply 500 nA rms (571 Hz); 200 uA rms (32 KHz)

Charge times:

• Less than 5 seconds to the recommended adult energy level (150 Joules) with a new, fully-charged battery installed
• Less than 6 seconds to the selected energy level (up to 200 Joules) with a new, fully charged battery installed
• Less than 15 seconds to the selected energy level while connected to AC power only
• The device powers on in manual defibrillation mode ready to deliver shock in less than:
  • 15 seconds with a new, fully-charged battery
• The device powers on in AED mode ready to deliver shock in less than:
  • 24 seconds with a new, fully-charged battery even after 15 discharges of maximum energy

Patient Impedance Range:

Minimum: 25 ohm (external defibrillation); 15 ohm (internal defibrillation)

Maximum: 250 ohm. Actual functional range may exceed these values

Size:

Approximately 7 in (17.8 cm) diagonal viewing area

Type:

Color TFT LCD

Resolution:

800 x 480 pixels (VGA) with 32 brightness levels per color

Sweep Speed:

25 mm/s ± 10% nominal (stationary trace; sweeping erase bar) for ECG and SpO₂; capnogram wave is 6.25 mm/s ± 10%

Wave Viewing Time:

6.5 sec ± 10%

Type:

Rechargeable, Lithium Ion; See battery label for capacity information

Approximate

Dimensions:

28.5 mm (H) x 80 mm (W) x 145.7 mm (L); 1.1 in (H) x 3.1 in (W) x 5.7 in (L)

Approximate Weight:

Approximately 0.44 kg (1 lb)

Capacity:

With a new fully charged battery, at 20 °C (68 °F), one of the following:

• 100 full-energy charge/shock cycles
• 2.5 hours of monitoring (ECG, EtCO₂ and SpO₂ continuously monitored and NBP sampled every 15 minutes) followed by 20 full-energy charge/shock cycles
• Two hours of pacing (180 ppm at 140 mA with 40 msec pulse) and monitoring (ECG, EtCO₂ and SpO₂ continuously monitored and NBP sampled every 15 minutes)

Battery Indicators:

Battery gauge on battery, capacity indicator on display, power indicators on front of device; flashing RFU indicator, audio beep and Low Battery messages on the display for low battery condition. When a low battery message first appears there is still enough energy for at least 10 minutes of monitoring and 6 maximum energy discharges.

Continuous ECG Strip:

The Print key starts and stops the strip. The printer can be configured to be run real time or with a 10 second delay. The strip prints the primary ECG lead and a second wave with event annotations and measurements.

Auto Printing:

The printer can be configured to automatically print on Mark Events, Charge, Shock and Alarm.

Reports:

The following can be printed:

• Event Summary (Long or Short)
• Vital Signs Trends
• Operational Check
• Configuration
• Status Log
• Device Information

Speed:

25 mm/s with an accuracy of ± 5 %

Amplitude Accuracy:

5 % for offset voltages of ± 300 mV at 5 Hz

Paper Size:

50 mm (W) x 20 m (L)

Temperature:

Operating temperature for the device: 0 °C to 45 °C (32 °F to 113 °F); Operating temperature range for EtCO₂: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature range for the device without battery: -20 °C to 70 °C (-4 °F to 158 °F)

Humidity:

Up to 95 % relative humidity

• EtCO₂ measurement meet all specifications during and after exposure to humidity conditions from 10 to 90 %
• Printer paper may jam if the paper is wet
• Thermal printer may be damaged if wet paper is allowed to dry while in contact with printer elements

Atmospheric Range:

Operating and Storage – 1014 mbar to 572 mbar (0 to 15,000 ft.; 0 to 4,500 m)

Shock:

Operating: Half-sine waveform, duration ≤ 11 ms, acceleration ≥ 15.3 G, 3 shocks per face

Non-operating: Trapezoidal waveform, acceleration 30 G, velocity change 7.42 m/s ± 10 % 1 shock per face

Water/Solid Ingress

Resistance:

Meets Ingress Protection level IP44

EMC:

Complies with the requirements of standard EN 60601-1-2:2002

Safety:

Meets EN 60601-2-4:2003, EN 60601-1:1990

Mode of Operation:

Continuous

AC Line Powered:

100 to 240 VAC, 50 or 60 Hz, 1 to 0.46 A, Class I Equipment

Battery Powered:

Minimum 14.4 V, Rechargeable Lithium Ion
