Mô tả sản phẩm: Phụ kiện khác dùng cho máy cắt dây Charmilles
| Various | |||||||||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application | ||||||
| C301 | - - -.342.997 | Cover | Robofil 3xx. 5xx. 1020. M series (20pcsset)for444.820 |
||||||||
 |
C302 | 100.343.525 | Robofil 3xx. 5xx series Contact brush annealing Ref. 100.342.185 |
||||||||
 |
C303 | - - -.351.624 | Arm | Robofil 3xx. 5xx series | |||||||
 |
C304 | 100.432.353 | Robofil 3xx. 5xx series Shaft for pinch roller |
||||||||
 |
C305 | 100.432.545 | Φ14.5xΦ2.5 11H |
Upper | Robofil 3xx. 5xx series Swivel nut |
||||||
 |
C306 | 200.434.002 | 19x25 | Lower | Robofil 2xx. 3xxF series Contact support lower head |
||||||
 |
C307 | 100.434.447 | Φ30xΦ12x6 | Cutter Z16 | Robofil 2xx. 3xxF series Cutter Z16 |
||||||
 |
C308 | 200.434.475 | Robofil x30F. x40F series Sapphire holder |
||||||||
 |
C309 | 100.434.525 | 16mmL | Robofil 3xx. 5xx. 10xx series Contact brush of holder-342.185 Material : Copper tungsten alloy |
|||||||
 |
C310 | 100.441.275 | 19x10x0.8T 19x10x1.0T |
Robofil 3xx. 5xx series Centering eye from tungsten carbide |
|||||||
 |
C311 | 100.444.728 | 15x15x24 | Lower | Robofil 1xxx. 1020. M series Contact support M |
||||||
 |
C312 | 100.444.744 | Φ14.5xΦ3.4 11H |
Upper | Robofil 3xx. 5xx. 1020. M series Swivel nut |
||||||
 |
C313 | 100.444.750 | 13x17x24 | Upper | Robofil 2xx. 3xx. 5xx. 1xxx. M series Contact support |
||||||
 |
C314 | 104.447.530 | M4x19+M6 | Upper | Robofil 2xx. 3xx. 5xx. 1xxx. M series Current transmitter |
||||||
 |
C315 | 100.444.760 | Φ14.5xΦ1.6 11H |
Lower | Robofil 2xx. 3xx. 5xx. 1020. M series Swivel nut |
||||||
| Various | ||||||||||||||||||||||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application | |||||||||||||||||||
 |
C316 | 100.445.423 | Φ34xΦ0.8 45H |
Common | Robofil 3xx. 5xx. 10xx series Spring for upper & lower water nozzle |
|||||||||||||||||||
 |
C317 | 100.446.201 | Φ35xΦ1.0 25H |
Lower | Robofil series Spring for lower water nozzle |
|||||||||||||||||||
 |
C318 | 100.447.060 | Φ35xΦ1.2 33H |
Common | Robofil series Spring for upper water nozzle |
|||||||||||||||||||
 |
C319 | 100.446.687 | 16x15x6T | Lower | Robofil 3xx. 5xx series Contact brush |
|||||||||||||||||||
 |
C320 | 100.446.736 | 70x9 | Cable | Robofil 2xx. 3xx. 5xx series Ground cable of contact brush (446.687) |
|||||||||||||||||||
 |
C321 | 100.447.762 | Robofil 2xx. 3xx. 5xx series Geared wheel |
|||||||||||||||||||||
 |
C322 | 100.448.679 | Φ20x16H | Lower | Robofil 3xx. 5xx series Contact sleeve |
|||||||||||||||||||
 |
C323 | 100.542.999 | Φ40xΦ12x6T | Pulley | Robofil 330F series Driving pulley of Lower head suitable Tungsten carbide |
|||||||||||||||||||
 |
C323G | 100.542.999 | Φ40xΦ12x6T | Pulley | Robofil 330F series Driving pulleu of Lower head suitable TiN coated : Gold color |
|||||||||||||||||||
 |
C325 | 100.942.008 | 15x300mm | Robofil 3xx. 5xx. 1020. 1030F series Ground cable |
||||||||||||||||||||
 |
C326 | 130.003.362 | Φ20xΦ16/12 19H |
Lower | Robofil 3xx. 5xx series Lower hjead |
|||||||||||||||||||
 |
C327 | 135.001.012 | Φ8/7.7xΦ2.3 H14 (3+8+3) |
Robofil 330F series Tungsten carbide Counter knife / Ref. ---542.998 |
||||||||||||||||||||
 |
C328 | 135.001.191 | Lower | Robofil 2xx. 3xx. 5xx series Stainless sleeve nut for lower guide |
||||||||||||||||||||
 |
C329 | 135.006.130 | Robofil 440CC series Power cable |
|||||||||||||||||||||
| C330 | 200.422.543 | 27.75x34.5H | Lower | Robofil 3xx. 5xx series Plastic casing box |
||||||||||||||||||||
 |
C331 | 200.422.631 | Robofil 3xx. 5xx series Cover for Mill |
|||||||||||||||||||||
| Various | ||||||||||||||||||||||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application | |||||||||||||||||||
 |
C332 | 200.448.671 | Φ14.5xΦ1.7 11H |
Lower | Robofil 1020.1 series Swivel nut |
|||||||||||||||||||
 |
C333 | 200.448.672 | Φ14.5xΦ3.5 11H |
Upper | Robofil 1020.1 series Swivel nut |
|||||||||||||||||||
 |
C334 | 200.434.002 | 25x19 | Lower | Robofil 230. 330F series Contact support lower head |
|||||||||||||||||||
 |
C335 | 200.442.870 | Φ14.5xΦ3.5 11H |
Upper | Robofil 2xx. 3xx. 5xx. 1020. M series Swivel nut |
|||||||||||||||||||
 |
C336 | 200.442.871 | Φ14.5xΦ1.6 11H |
Lower | Robofil 2xx. 3xx. 5xx. 1020. M series Swivel nut |
|||||||||||||||||||
 |
C337 | 200.448.792 | Φ9.0x4.1H | Cutter | Robofil 1xx. 3xx. 5xx. 10xx. M/Fseries Material:CermitorTungstencarbide Ref. 442.848 |
|||||||||||||||||||
 |
C338 | 200.441.192 | 0.7x15x3545 | Robofil 1000. 1020 series Belt for spool drive-one side black |
||||||||||||||||||||
 |
C339 | 200.447.805 | 0.7x20x485 | Robofil 1000. 1020 series Belt for spool drive-one side black |
||||||||||||||||||||
 |
C340 | 200.542.918 | Φ14.5xΦ3.5 16H |
Upper | Robofil 2xx. 3xx. 5xx. 1020. M series Swivel nut |
|||||||||||||||||||
 |
C341 | 200.544.240 | Robofil 3xx. 5xx. 1020. 1030F series Brake roller empty |
|||||||||||||||||||||
 |
C342 | 204.448.200 | Robofil 1xx. 2xx. 4xx. 1020. M series Ceramic roller subassembly |
|||||||||||||||||||||
 |
C345 | 135.009.523 | Robofil series | |||||||||||||||||||||
 |
C346 | 200.543.838 | Robofil series | |||||||||||||||||||||
 |
C351 | 100.441.726 | Robofil 3xx. 5xx. 1020. 1030F series Flushing nozzle spring |
|||||||||||||||||||||
 |
C352 | 100.542.854 | Robofil 3xx. 5xx. 1020. 1030F series Pressure spring |
|||||||||||||||||||||
 |
C353 | 100.543.287 | Robofil 3xx. 5xx. 1020. 1030F series Lower head spring |
|||||||||||||||||||||
