Mô tả sản phẩm: Nắp chụp nước dùng cho máy cắt dây Fanuc
| Flushing Nozzle | |||||
| Picture |
Code No. |
Orignal P/No. |
Dimension |
Position |
Application |
 |
F126 |
A290-8102-X723 |
Φ58x19T |
Upper |
α-A. B series AWF type Nozzle base with 4 screw hole |
 |
F127 |
A290-8110-Y723 |
Φ58x19T |
Upper |
α-C. iA. iC series AWF type Nozzle base with 5 screw hole |
 |
F201A |
~ A290-8021-Y745 A290-8021-Y705 |
Φ 3 / Φ4 Φ 5.5 Φ 8.0 |
Common |
O. P. Q. R. T. W series Manual type / 3Hole type |
 |
F201B |
~ A290-8021-Y745 A290-8021-Y705 |
Φ 3 / Φ4 Φ 5.5 Φ 8.0 |
Common |
O. P. Q. R. T. W series Manual type / 1Hole type |
 |
F201L |
Lower |
O. P. Q. R. T. W series Manual type / Long type |
||
 |
F202 |
~ ~ A290-8021-Y755 |
Φ 3 Φ 4 Φ 5.5 |
Lower |
O. P. Q. R. T. W series Manual type |
 |
F204 |
A290-8037-X879 A290-8037-X870 |
Φ5.5 Φ13 |
Lower |
W-1.2.3.4 series AWF type |
 |
F205 |
A290-8032-Y611 A290-8037-X689 |
Φ5.5 Φ11 |
Upper |
W-1.2.3.4 series AWF type |
 |
F206-1 |
A290-8021-V722 |
Common |
O. P. Q. R. T. W series Nozzle cap for F201 & 202 Material : Stainless steel |
|
 |
F206-2 |
A290-8021-V722 |
Common |
O. P. Q. R. T. W series Nozzle cap for F201 & 202 Material : Brass |
|
 |
F206-3 |
Common |
O. P. Q. R. T. W series Stainless nozzle cap for F201/202 |
||
 |
F206 SET |
Common |
O. P. Q. R. T. W series Nozzle dies holder set for F201/202 |
||
 |
F207 |
A290-8048-X771 |
Φ7 |
Upper |
W-0 series Manual type / Φ24x16.5H |
 |
F208 |
A290-8048-X772 |
Φ7 |
Lower |
W-0 series Manual type / Φ24x16H |
 |
F209 |
A290-8111-X772 A290-8111-X774 A290-8111-X776 |
Φ 2 Φ 4 Φ 6.5 |
Upper |
α-A. B. C. iA. iB series Manual type / OD40x38H |
 |
F210 |
A290-8101-X755 |
Φ16 |
Lower |
α-A. B. C. iA. iB series Nozzle holder for F211 / OD40x23H |
 |
F211 |
A290-8101-X774 A290-8101-X756 A290-8101-X777 |
Φ2 / Φ4 Φ6.5 Φ10 |
Lower |
α-A. B. C. iA. iB series Manual type / OD27x16H |
 |
F212 |
A290-8102-X775 A290-8102-X751 A290-8102-X752 |
Φ2 Φ4 (=F214) Φ6.5 Φ12 (=F216) |
Upper |
α-A. B. C. iA. iB series AWF type / OD40x23.5H Acetal |
 |
F212-1 |
A290-8102-X775 A290-8102-X751 A290-8102-X752 |
Φ2 Φ4 (=F214) Φ6.5 Φ12 (=F216) |
Upper |
α-A. B. C. iA. iB series AWF type / OD40x23.5H Acryl |
 |
F213 |
A290-8104-X774 A290-8102-X774 A290-8102-X771 A290-8102-X772 |
Φ2.0 Φ4(=F215) Φ6.5 Φ12 (=F217) |
Lower |
α-A. B. C. iA. iB series AWF type / OD40x25H Acetal |
 |
F213-1 |
A290-8104-X774 A290-8102-X774 A290-8102-X771 A290-8102-X772 |
Φ2.0 Φ4 (=F215) Φ6.5 Φ12(=F217) |
Lower |
α-A. B. C. iA. iB series AWF type / OD40x25H Acryl |
 |
F218 |
~ ~ A290-8109-X776 |
Φ2.0 Φ4.0 Φ6.5 |
Upper |
α-0C. 1C series Manual type / OD40x34H |
