Màn hình cảm ứng Cimon Touch T15FP

Features of CIMON-TOUCH
-Full Tag DS Version CIMON SCADA Included
-Low Voltage Mobile CPU
-Easy and User-Friendly Software (CIMON-SCADA)
-High Performance with Excellent Stability
-Very Fast and Reliable SSD Storage
-Flexible Communication with Upper and Lower Systems through a Variety of Interfaces Provided

Specifications

Touch Screen                                            1024 x 768 (Analog 8-Wire Resistive)
Color                                                        16.7M
Touch Controller                                         PenMount USB Controller
CPU                                                         Intel ATOM Processor N450 1.6GHz (Fanless)
RAM                                                         DDR2 SDRAM 1GB
Storage                                                    SSD 120GByte
Graphic Chip                                              Intel GMA 3150 integrated
Display                                                     15" TFT LCD
                                                              CRT Output (15P DSUB)
Serial                                           RS232/422/485 1 port (COM1)  /  RS232C 3 port (COM2-4)
Ethernet                                                  Gigabit Ethernet 2 port
Parallel                                                    1 port
PS/2                                                       Keyboard & Mouse
USB                                                        USB 2.0  4 port
Audio                                                      1 port
CD-ROM                                                   1 slot
PCI Slot                                                   1 slot
Operating System                                      Windows Embedded POS Ready 2009
Utility Program                                EWF (Disk Image Safeguard) / Rescue (Factory Default

                                                   Recovering Tool)
Power AC                                                110V / 220V

Basic Specification
Energy consumption                        60watts or less
Ambient temperature                       0℃ ~ 50℃
Storage temperature                      -20℃ ~ 60℃
Ambient humidity                            10%RH ~ 85%RH(below 29℃, No dew condensation)
Storage humidity                            10%RH ~ 85%RH(below 39℃, No dew condensation)
Environment condition                      800hPa~1114hPa(2000m or less)
Dust                                             0.1mg/m3 or less
Pollution degree                              Pollution degree 2
Corrosion gas                                 None
Vibration resistance                         HDD storage type 4.9m/S2,10Hz~25Hz in X, Y, Z (80 min)
                                                   CF storage type 9.8m/S2, 10Hz~25Hz in X, Y, Z (80 min)
                                                   SSD storage type 9.8m/S2, 10Hz~25Hz in X, Y, Z (80 min)
Noise resistance                             Impulse, EFT/Burse, Surge,  ±2KV, 1uS
Static discharge resistance              4kV(IEC61000-4-2 LEVEL 3)
