| Inputs |
Input overload |
| 3 CAST via 4-pin bayonet connectors |
CAST: 11 mA RMS |
| 3 balanced via XLR connectors |
Balanced: 9 V RMS |
| 4 single-ended via RCA connectors |
Single-ended: 18 V RMS |
| Tape input |
Output overload |
| 1 balanced via XLR connector or |
CAST: 22 mA RMS |
| 1 single-ended via RCA connector, user configurable |
Balanced: 20 V RMS |
| Main outputs |
Single-ended: 10 V RMS |
| 2 CAST via 4-pin bayonet connectors |
Frequency response |
| 1 balanced via XLR connector |
20 Hz to 20 kHz +/-0.01 dB |
| 1 single-ended via RCA connector |
Balanced or single-ended inputs: |
| Tape outputs |
0.2 Hz to 1.3 MHz +0, -3 dB |
| 1 balanced via XLR connector and |
CAST inputs: |
| 1 single-ended via RCA connector, |
0.2 Hz to 2 MHz +0, -3 dB |
| buffered, connected to main inputselection bus |
Total harmonic distortion plus noise |
| 1 balanced via XLR connector and |
Balanced Output: |
| 1 single-ended via RCA connector, buffered, connected to a |
<0.003%, 20 Hz to 20 kHz, 4 V RMS |
| dedicated record-output bus |
| Control inputs |
CAST output: 4 mA RMS |
| 1 RS-232 input via a 9-pin D-subminiature connector |
Signal-to-noise ratio |
| 1 remote IR detector input via a 3-conductor 3.5 mm connector |
4 V RMS balanced or 4 mA RMS CAST output |
| 1 12 VDC trigger input via 3.5 mm connector |
Wideband, unweighted: >97 dB |
| 1 preamplifier link via an RJ-45 connector |
"A" weighted: >104 dB |
| Control outputs |
Power consumption |
| 2 individually programmable 12 VDC trigger outputs via |
Standby: 50 W |
| 3.5 mm connectors |
| 1 preamplifier link via an RJ-45 connector |
Power on: 80 W |
| Power output |
Power on, with KPE: 90 W |
| 1 phono power output (+/-20 VDC) for KPE via a 9-pin |
Dimensions |
| D-subminiature connector |
| Input impedance |
Preamplifier only: |
| CAST: 35 Ohms |
17.3 in.W x 3.7 in. H x 18.5 in. D |
| Balanced: 40 k Ohms |
43.8 cm W x 9.5 cm H x 47 cm D |
| Single-ended: 20 k Ohms |
Power supply only: |
| Output impedance |
17.3 in. W x 3.7 in. H x 17.3 in. D |
| CAST: >1 M Ohms |
43.8 cm W x 9.5 cm H x 43.8 cm D |
| Balanced: 250 Ohms |
Preamplifier channel: |
| Single-ended: 125 Ohms |
17.3 in. W x 7.3 in. H x 18.5 in. D |
| Gain |
43.8 cm W x 18.5 cm H x 47 cm D |
| 12 dB (CAST or balanced output) |
Stereo pair: |
| 6 dB (single-ended output) |
17.3 in. W x 14.6 in. H x 18.5 in. D |
| Volume control |
43.8 cm W x 37.1 cm H x 47 cm D |
| Balanced, current-mode, |
Weight |
| 16-bit, discrete R-2R ladder |
Shipped: 69 lbs., 31.2 kg |
|
Preamplifier only: 21 lbs., 9.5 kg |
|
Power supply only: 31 lbs., 14 kg |
