Alcatel-Lucent OmniAccess 5324 BG OA5324-60P-EU

OA5324 BG with 1 pair SHDSL (or Ethernet WAN), 2 port ISDN PRI, 4 ports 10/100 Switch and 1 port USB. Includes external AC power supply.

WAN interfaces
    ADSL/ADSL2/ADSL2+ ports (RJ-11)
        Up to 24 Mb/s downstream
        Up to 3.072 Mb/s upstream
        G.992.1 (G.dmt)
        G.992.2 (G.lite)
        G.992.3 (G.dmt.bis) ADSL2
        G.992.5 ADSL2+
    Ethernet ports (RJ-45)
        10/100Base-T/TX

User interfaces
    FXS ports (4xRJ-11)
        Configurable line impedance 600-ohm or complex (TBR21)
        Dual-tone multi-frequency (DTMF) and loop disconnect dialing
        Line reversal
        REN of 4
        CLASS features
        Configurable
            Ring frequency and cadence ring signal = 50 V rms
            On-hook battery voltage = 48 V
            DC loop current = 25 mA
    ISDN2/BRI S0 ports (RJ-45)
        CTR3-compliant
        NT mode
        Point-to-point and point-to-multipoint
        100-ohm termination
        Power source 1 support (NT)
        Supplementary service support
        Multiple subscriber numbering (MSN)
        item
    LAN ports (4xRJ-45)
        10/100Base-T/TX
    USB 2.0 (1)

WAN
    Eight ATM PVCs on WAN
    Bridged and routed encapsulation – RFC 1483
    Logical Link Control/Sub-network Access Protocol (LLC/SNAP), Virtual Circuit Multiplexing (VC-Mux), High-level Data Link Control (HDLC)
    MAC Encapsulated Routing (MER)
    Point-to-Point Protocol over ATM (PPPoA), Point-to-Point Protocol over Ethernet (PPPoE), Password Authentication Protocol (PAP), Challenge-Handshake Authentication Protocol (CHAP)
    IP over ATM (IPoA) – RFC 2225
    High availability using Ethernet WAN as backup

Routing and switching
    Up to 16 802.1q VLANs
    Port-based VLAN, independent VLAN learning (IVL) and shared VLAN learning (SVL)
    Static Routing and Routing Information Protocol (RIP) v1/v2
    Network address translation (NAT), network address port translation (NAPT), port address translation (PAT)
    IP multicast forwarding
    Internet Gateway Multicast Protocol (IGMP) v1/v2 and proxy
    Dynamic Host Configuration Protocol (DHCP) server, client, relay
    Transparent bridging
    Simple traversal of UDP through NATs (STUN)
    IPv6 support
        Dual IP stack
        Addressing architecture
        Internet Control Message Protocol (ICMP) v6
        DHCP v6
        Generic Packet Tunneling
        Path (MTU)

Security
    Stateful bidirectional firewall
    IP and Media Access Control (MAC) filtering
    NAT/NAPT
    Intrusion detection system (IDS) – port scan, denial of service (DoS) and spoofing
    DMZ support
    IPSec termination and initiation
    LAN-to-LAN and teleworker-to-LAN VPN
    Manual keys
    Authentication: Null, MD5 and SHA-1
    Internet Key Exchange (IKE) authentication: Pre-shared Key, Digital Signature Algorithm (DSA) and Rivest, Shamir and Adleman (RSA)
    Hardware-accelerated Triple Data Encryption Standard (3DES)/Data Encryption Standard (DES) and Advanced Encryption Standard (AES)
    NAT traversal (NAT-T)
    Password access
    Restricted access

Voice protocols
    SIP: RFC 3261, RFC 2453
        Single port registration
        Trunking
            Multiple device registration
            Single device registration
            No registration
            POTS trunking
        Tel URI
    Comprehensive ISDN supplementary services
    Media Gateway Control Protocol (MGCP): Network-based Call Signaling (NCS), RFC 2705, RFC 3435

VoIP CODECs
    G.711 a-law, μ-law, 64 kb/s
    G.726/G.721 ADPCM, 32 kb/s
    G.729ab CS-ACELP, 8 kb/s
    G.128 LEX 32 ms
    Silence detection
    Comfort noise generation
    DTMF detection and relay
    Fax and modem detection
    T.38 fax relay
    Variable length dynamic jitter buffer
    Packet loss compensation (PLC)
    RFC 4040 – Clear mode

Quality of service
    ATM: CBR, VBR-rt, VBR-nrt
    UBR, UBR+
    IP: Type of service (TOS)/differentiated services code point (DSCP) bit prioritization
    VLAN tagging and 802.1p
    Differentiated services (DiffServ)
    Packet classifier and metering
    Transmit scheduler
    Optional algorithmic dropping
    VC traffic shaping on AAL5

Configuration and management
    HTTP: Telnet, SNMP, TR-069
    Local or remote access
    Firmware upgrade of HTTP, TFTP, FTP
    Support of TR-69, TR-104 and TR-111
    ICMP ping, syslog, trace route
    Automatic provisioning
    Syslog
    Event log

LED indicators
    Power, DSL, data, voice, WLAN

Environmental
    Operating temperature: 0°C to 40°C (32°F to 104°F)
    Storage: -10°C to +60°C (14°F to 140°F)
    Relative humidity: 5% to 95%

Regulatory
    CE marked
    RoHS-compliant
    Safety: EN60950
    RFI: Emissions EN55022
    RFI: Imm
