System Information
| CPU |
- Multimedia SoC (System-on-Chip)
|
| Flash |
|
| RAM |
|
|
Camera Features
| Image sensor |
|
| Maximum Resolution |
|
| Lens Type |
|
| Focal Length |
|
| Aperture |
|
| Auto-iris |
|
| Field of View |
- 36° ~ 82° (horizontal)
- 27° ~ 62° (vertical)
- 44° ~ 107° (diagonal)
|
| Shutter Time |
|
| WDR Technology |
|
| Day & Night |
- Removable IR-cut filter for day & night function
- Smart IR Technology to Avoid Overexposure
|
| Minimum Illumination |
- 0.1 Lux @ F1.2 ( Color )
- 0.001 Lux @ F1.2( B/W )
|
| Pan / Tilt / Zoom |
- ePTZ: 48x digital zoom (4x on IE plug-in,12x built in)
|
| IR Illuminators |
- Built-in IR illuminators, effective up to 30 meters
- IR LED*4 with Smart IR Technology
|
| On-board Storage |
|
|
Video
| Compression |
|
| Maximum Frame Rate |
- H.264:
- 30 fps at 2048x1536
- 60 fps at 1920x1080
- MPEG-4:
- 30 fps at 2048x1536
- 52 fps at 1920x1080
- MJPEG:
- 30 fps at 2048x1536
- 60 fps at 1920x1080
|
| Maximum Streams |
|
| S/N Ratio |
|
| Dynamic Range |
|
| Video Streaming |
- Adjustable resolution, quality and bitrate
|
| Image Settings |
- Adjustable image size, quality and bit rate
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, Scheduled profile settings
- 3D Noise Reduction, Smart Stream
|
|
Audio
| Audio Capability |
- Audio input/output (full duplex)
|
| Compression |
- GSM-AMR, AAC, G.711, G.726
|
| Interface |
- External microphone input and Output
|
|
Network
| Users |
- Live viewing for up to 10 clients
|
| Protocols |
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
|
| ONVIF |
- Supported, specification available at www.onvif.org
|
| Interface |
- 10Base-T/100 BaseTX Ethernet (RJ-45)
|
|
Intelligent Video
| Video Motion Detection |
- Triple-window video motion detection
|
|
Alarm and Event
| Alarm Triggers |
- Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
|
| Alarm Events |
- Event notification using HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
| Smart Focus System |
- Remote focus & easy focus
|
| Connectors |
- RJ-45 cable connector for Network/PoE connection
- Audio input
- Audio output
- AC 24V power input
- DC 12V power inout
- Digital input*1
- Digital output*1
- Analog video output
|
| LED Indicator |
- System power and status indicator
|
| Power input |
- DC 12V
- AC 24V
- IEEE 802.3af PoE Class 3
|
| Power consumption |
- DC: Max. 26 W (Heater on), 7.5 W (Heater off)
- AC: Max. 25 W (Heater on), 7.7 W (Heater off)
- PoE: Max. 11 W
|
| Dimensions |
|
| Weight |
- Net: 1,335g (with bracket)
|
| Casing |
- Weather-proof IP67-rated housing
|
| Safety Certifications |
- CE, LVD, FCC Class A, VCCI, C-Tick, UL
|
| Operating Temperature |
- Starting Temperature: -40°C ~ 50°C ( PoE: -10°C ~ 50°C )
- Working Temperature: -50°C ~ 50°C
|
| Warranty |
|
|
System Requirements
| Operating System |
- Microsoft Windows 7/Vista/XP/2000
|
| Browser |
- Mozilla Firefox 7~10 (Streaming only)
- Internet Explorer 7.x or 8.x
|
| Other Players |
- VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
