| odel |
IP38VC |
| Image Sensor |
1/3" 3.1 megapixel progressive CMOS (Aptina AR0331), WDR |
| Resolution |
20fps (2048*1536)(3MP), 30fps (1920x1080)(1080P), 30fps (1280x720P)(720P), 30fps (640x352)(VGA), 30fps (352x192))(QVGA) |
| Pixels |
3.1MP:2048(H)*1536(V) |
| Scanning System |
Progressive Scanning |
| WDR |
Yes |
| Compression Format |
H.264 High prfile, Audio G.711 |
| OS |
Embedded Linux |
| Video Output |
Ethernet RJ45, CVBS out |
| Bit Rate |
64Kbps ~ 12Mbps |
| Recording Mode |
Schedule, Manual, Motion, Sensor |
| Dual Stream |
Yes |
| Web Browser Access |
Yes |
| Network |
Ethernet RJ45, 10/100mbps |
| Protocol |
TCP/IP, VLC(PS/TS) Stream Media protocol, RTSP, RTMP, HTTP, UDP, RTP/RTCP, UPNP, SMTP, FTP, DDNS, DNS, PPPoE, DHCP |
| Interface |
Audio 1in/1out, RS485 optional |
| Alarm I/O |
1 input; 1 output optional |
| Storage Interface |
TF card optional, Max. 32G |
| Waterproof Rate |
IP66 |
| Day & Night |
Auto |
| IR-CUT |
Yes |
| Minimum Illumination |
0Lux @ IR ON |
| IR Distance |
IR2=20-30M; IR3=40-60M; IR6=60-80M; IR7=100-120M; IR8=120-150M |
| Lens |
4mm, 6mm, 8mm, 12mm, 16mm, 25mm, 2.8-12mm 2MP lens optional |
| S/N Ratio |
More than 58db |
| Power Supply |
DC12V, Max.3W |
| Operating Temperature |
-10 ~ 50 °C (14 ~ 122 °F) |
| Relative Humidity |
10%-90% Non-condensing |
| Unit Dimension |
130mm(D)*220mm |
| Unit Weight |
850g |
| Compatibility |
ONVIF2.0 (SDK,CGI available) |
| Wifi |
Optional |
| POE |
802.3af (optional) |
| Warranty |
1 Year |
| MODEL SELECTION |
| IP38VC |
4mm lens, White Color |
| IP38VC-P |
With POE |
| IP38VC-T |
With TF Card slot |
| IP38VC-W |
With WIFI |
| N/A |
No other color |
| ACCESSORY OPTIONS |
| Fixed Lens |
2.8mm, 4mm, 6mm, 8mm, 12mm, 16mm, 25mm 3MP Fixed Lens optional |
| Varifocal Lens |
2.8-12mm 3MP lens optional |
| Camera bracket |
Optional |
