Mô tả sản phẩm: Acesee ADV25P200
| Model NO. | ADV25P100 | ADV25P130 | ADV25P200 |
| Camera | |||
| Image Sensor | 1/4" Omnivision 1MP CMOS Sensor OV9712 |
1/3" Aptina 1.3MP CMOS Sensor AR0130 |
1/3" SONY 2MP CMOS Sensor IMX122 |
| Main processor | DM365 (TI DaVinci™) | DM365 (TI DaVinci™) | DM368 (TI DaVinci™) |
| Resolution | 720P | 960P | 1080P |
| Effective Pixels | 1280(H)*720(V) | 1280(H)*960(V) | 1920(H)*1080(V) |
| TV System | PAL/NTSC | ||
| Electronic Shutter Time | Auto: PAL 1/50-1/100, 000Sec; NTSC 1/60-1/100, 000Sec | ||
| Sync System | Internal | ||
| Usable Illumination | 1Lux | 0.1Lux | 1Lux |
| S/N Ratio | ≥52dB | ||
| Scanning System | Progressive | ||
| Video Output | Network | ||
| Lens | |||
| Focus Length | 2.8-12mm | ||
| Focus Control | Manual | ||
| Lens Type | Manual | ||
| Pixels | 2M Pixels | 2M Pixels | 3M Pixels |
| Night Vision | |||
| Infrared LED | ￠5X30PCS | ||
| Infrared Distance | 25M | ||
| IR Status | Under 10 Lux By CDS | ||
| IR Power On | CDS Auto Control | ||
| Network | |||
| Ethernet | RJ-45 (10/100Base-T) | ||
| Protocol | IPv4/IPv6, HTTP, TCP/IP, RTSP, UDP, SMTP, DHCP, DNS, DDNS | ||
| ONVIF | Support ONVIF 2.0 | ||
| P2P | YES, Support | ||
| POE | NO | ||
| WIFI | N/A | ||
| Frame Rate | 25fps(PAL)/30fps (NTSC) ( 1-25/1-30 FPS adjustable) | ||
| DualStream | Main Stream: 1280*720 Sub Stream: 704*576, 352*288 |
Main Stream: 1280*960, 1280*720 Sub Stream: 704*576, 352*288 |
Main Stream: 1920*1080, 1280*720 Sub Stream: 704*576, 352*288 |
| IE Brower | IE6-10 | ||
| Smart Phone | iPhone, iPad, Android | ||
| Camera Features | |||
| Day/Night | Color/ B&W | Color/ B&W | Color/ B&W |
| Compression | H.264 | ||
| Picture config | Saturation/Brightness/Contrast /Sharpness | ||
| Recording Mode | NVR/Multiwindow/Web | ||
| Language | English | ||
| General | |||
| Vandalproof Housing | YES | ||
| Lens Angle Adjustment | YES, 3-Axis Bracket Built-in | ||
| IR Cut Filter | YES | ||
| Operation Temperature | -10℃ ~ +50℃ RH95% Max | ||
| Storage Temperature | -20℃ ~ +60℃ RH95% Max | ||
| Power Source | DC12V±10%, 1000mA | ||
| Dimension | ￠135 x 110(H)mm | ||
| Weight | 2Kg | ||
