Mô tả sản phẩm: Hunt HLC-84BD
|
|
||
|---|---|---|
|
■ Support Full HD 1080P Real Time
■ Digital Noise Reduction ■ Digital Wide Dynamic Range ■ Shutter Speed adjustion ■ Sense Up adjustion ■ Power Over Ethernet (Option) ■ H.264/ MJPEG/ MPEG4 compression ■ Micro SD card backup ■ DI/DO ■ Support iPhone/iPad/Android ■ Triple Streaming ■ SDK for Software Integration ■ Free Bundle 36 ch recording software |
 |
|
|
Specifications
|
|
|---|---|
| CPU | ARM 9, 32 bit RISC |
| RAM | 256MB |
| Flash | 16MB |
| Image Sensor | 1/2.7” CMOS sensor |
| Lens Type | 4.2mm @ F1.6 |
| Angle of View | 53.1(H), 29.5(V) |
| Sensitivity | 0.5 Lux (AGC On) |
| Shutter Time | 1 / 5 ~ 1 / 10,000 sec |
| Audio |
G.711(64K) and G.726(32K,24K) audio compression |
| IO | DI / DO |
| Power over Ethernet | Yes, Optional |
| Power |
12V DC Power consumption Max：2.64W |
| Operating Temperature | 0℃~40℃ |
| Dimensions | 59mm x 93.7(mm)x 45.5(mm) |
| Weight | 240g |
|
Network
|
|
| Ethernet | 10/ 100 Base-T |
| Network Protocol | IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE 802.1X, RTSP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, 3GPP, SAMBA |
| Wireless (Optional) | |
| Wireless | 802.11 b/g/n |
| Security | WEP,WPA-PSK,WPA2-PSK |
|
System
|
|
| Video Resolution | 1920x1080@25fps, 1280x720@25fps, 640x480@30fps, 320x240@30fps, 176x144@30fps |
| Video Adjust | Brightness, Contrast, Hue, Saturation, Sharpness, Shutter Speed adjustable, AGC, Sense-Up, D-WDR, Flip, Mirror, Noise reduction, Day&Night adjustable |
| Triple Streaming | Yes |
| Image Snapshot | Yes |
| Full Screen Monitoring | Yes |
| Privacy Mask | Yes, 3 different areas |
| Compression Format | H.264/ M-JPEG/ MPEG4 |
| Video Bitrates Adjust | CBR, VBR |
| Motion Detection | Yes, 3 different areas |
| Triggered Action | Mail, FTP, Save to SD card, DO, SAMBA |
| Pre/ Post Alarm | Yes, configurable |
| Security | Password protection, IP address filtering, HTTPS encrypted data transmission, 802.1X port-based authentication for network protection, QoS/DSCP |
| Firmware Upgrade | HTTP mode, can be upgraded remotely |
| Simultaneous Connection | Up to 10 |
|
SD card management
|
|
| Recording Trigger | Motion Detection, IP check, Network break down (wire only),schedule, DI |
| Video Format | AVI, JPEG |
| Video Playback | Yes |
| Delete Files | Yes |
|
Client system requirements
|
|
| OS | Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or above, Chrome, Safari, Firefox |
| Mobile Support | iOS 4.3 or above, Android 1.6 or above |
| Hardware | |
| Suggested | Intel Dual Core 2.53G,RAM: 1024MB, Graphic card: 128MB |
