Mô tả sản phẩm: Bộ chuyển đổi UTEK UT-8002 USB sang 2 cổng RS-232
Feature
1. Standards: conforming to USBV1.0, 1.1 and 2.0 and EIA RS-232.
2. USB signals: VCC, DATA+, DATA-, GND and FG..
3. RS-232 signals: DCD RXD TXD DTR GND DSR RTS CTS RI
4. Working mode: asynchronous point-to-point.
5. Direction control: adoption of automatic data stream control for automatic recognition and control of data transmission direction.
6. Baud rate: 300-921.6Kbps, automatic detection of the transmission rate of the serial interface signal.
7. Load capacity: point-to-point communication mode is supported
8. Transmission distance: 5 meters for RS-232 and less than 5 meters for USB.
9. Protection:3000A lightning strike protection for RS-232
10. Interface forms: A interface male connector and 5.08 binding port for USB.
11. Signal indication: 3 indicator lights for Power (PWR), Send (TXD) and Receive (RXD).
12. Transmission media: twisted-pair cable or shielded cable.
13. Dimensions: 1530mm×33mm×16mm.
14. Working environment: -40℃ to 85℃, relative humidity 5% to 95%.
15. Support system: Windows 98/98SE/ME/ CE.NET 4.2 & 5.0/2000/Server 2003/XP 64-bit/ Embedded. Windows 7 x64/ Windows Vista/ MAC OS 8 / 9, OS-X/ Linux 2.4 and greater
