Mô tả sản phẩm: Kramer 8x8 Multiformat Video & Balanced Audio Matrix Switcher
The Kramer 8x8 Multiformat Video & Balanced Audio Matrix Switcher allows you to switch between any of the 8 high-resolution multiformat inputs such as composite video, s-Video (Y/C), component video (Y, Pb, and Pr), balanced stereo audio, S/PDIF digital audio, and 8 outputs independently. The high-performance device can route any or all of the inputs to any or all outputs simultaneously.
In addition to HDTV compatibility, the 8x8 Multiformat Video & Balanced Audio Matrix Switcher features video bandwidth of over 350MHz (-3dB) fully loaded. You can recall and execute common video and audio configurations and audio gain status for each output using the preset memory locations. With the Take Button you can execute multiple switches simultaneously. Front Panel Lockout prevents tampering.
Analog Audio Breakaway Switching helps in switching audio independently from video. Audio Level Controls can be used to adjust the gain signal level of each input and output and match it with various other sources. In addition, the 8x8 Multiformat Video & Balanced Audio Matrix Switcher features Vertical Interval Switching that permits switching during the vertical interval to ensure glitch-free switching with genlocked sources.
The 8x8 Multiformat Video & Balanced Audio Matrix Switcher can be controlled using the front panel buttons or remotely via RS-232, RS-485, Ethernet, IR remote control or an external IR remote receiver. It has a standard 19” rack mount size, fits 3U rack space, and requires a 100-240V AC power supply.
In addition to HDTV compatibility, the 8x8 Multiformat Video & Balanced Audio Matrix Switcher features video bandwidth of over 350MHz (-3dB) fully loaded. You can recall and execute common video and audio configurations and audio gain status for each output using the preset memory locations. With the Take Button you can execute multiple switches simultaneously. Front Panel Lockout prevents tampering.
Analog Audio Breakaway Switching helps in switching audio independently from video. Audio Level Controls can be used to adjust the gain signal level of each input and output and match it with various other sources. In addition, the 8x8 Multiformat Video & Balanced Audio Matrix Switcher features Vertical Interval Switching that permits switching during the vertical interval to ensure glitch-free switching with genlocked sources.
The 8x8 Multiformat Video & Balanced Audio Matrix Switcher can be controlled using the front panel buttons or remotely via RS-232, RS-485, Ethernet, IR remote control or an external IR remote receiver. It has a standard 19” rack mount size, fits 3U rack space, and requires a 100-240V AC power supply.
- Allows you to switch between any of the 8 high-resolution multiformat inputs such as composite video, s-Video (Y/C), component video (Y, Pb, and Pr), balanced stereo audio, S/PDIF digital audio, and 8 outputs independently
- Routes any or all of the inputs to any or all outputs simultaneously
- HDTV compatible
- Features video bandwidth of over 350MHz (-3dB) fully loaded
- Preset memory locations - recall and execute common video and audio configurations and audio gain status for each output
- Take Button - execute multiple switches simultaneously
- Front Panel Lockout - prevent tampering
- Analog Audio Breakaway Switching - helps in switching audio independently from video
- Audio Level Controls - adjust the gain signal level of each input and output and match it with various other sources
- Vertical Interval Switching - permits switching during the vertical interval to ensure glitch-free switching with genlocked sources
- Control - front panel buttons, or remotely via RS-485, RS-232 serial commands, Ethernet, embedded Web page, external IR remote receiver or IR remote
- Standard 19" rack mount size
- Fits 3U rack space (includes rack ears)
- Requires a 100-240V AC power supply
| Inputs | 5x8 composite video 0.7Vpp/75Ω and S/PDIF digital audio or s-Video 0.7Vpp/75Ω (Y), 0.7Vpp/75Ω (C); component video 0.7Vpp/75Ω on BNC connectors; 8 balanced stereo audio, 2.2V/10kΩ on detachable terminal blocks; 1 external sync 1Vpp on a BNC connector |
| Outputs | 5x8 composite video 0.7Vpp/75Ω and S/PDIF digital audio or s-Video 0.7Vpp/75Ω (Y), 0.7Vpp/75Ω (C); component video 0.7Vpp/75Ω on BNC connectors; 8 balanced stereo audio, 2.2V/150Ω on detachable terminal blocks |
| Maximum Output Level | Video: 2.4Vpp Audio: 15Vpp @max gain |
| Bandwidth -3dB Point | Video: 350MHz, fully loaded Audio: 22kHz |
| S/N Ratio | Video: 74dB Audio: 81dB @1kHz |
| Crosstalk | Video: -47dB @5MHz Audio: <-57dB @20kHz |
| Differential Gain | 0.05 |
| Differential Phase | 0.05 |
| Controls | Manual, RS-232, RS-485 or Ethernet |
| Audio THD + Noise | 0.089% @1kHz |
| Power Source | 100-240V AC, 50/60Hz, 23VA |
| Dimensions (WxDxH) | 19 x 7 x 5.25" (48 x 18 x 13cm) |
| Options | External remote IR receiver cable |
| Weight (Approx.) | 12.2 lb (5.5 kg) |
