Mô tả sản phẩm: Kramer VS-88HCB 8x8 Universal Matrix Switcher
The VS-88HCB 8x8 Universal Matrix Switcher from Kramer is designed to manage composite video, component video (Y, Pb, and Pr), balanced stereo audio, and S/PDIF digital audio signals. It can route any or all inputs to any or all outputs simultaneously.
- This matrix switcher is designed to manage composite video, component video (Y, Pb, and Pr), balanced stereo audio, and S/PDIF digital audio signals
- It supports bandwidth up to 300MHz (-3dB) fully loaded
- This unit is HDTV-compatible
- Control options include: front panel, RS-232, RS-485, Ethernet, IR remote (included), and remote IR receiver (optional)
- It features separate composite-video and component-video inputs
- A take button executes multiple switches at the same time
- Store multiple switches as presets to be recalled and executed as needed
- Analog audio breakaway switching is available
- This unit can be mounted in 3U of a standard equipment rack
| Inputs | (5) x (8) composite video 1Vpp/75 Ohms and S/PDIF digital audio or S-video 1Vpp/75 Ohms (Y), 0.3Vpp/75 Ohms (C); and component video 1Vpp/0.7Vpp/75 Ohms on BNC connectors (8) balanced stereo audio, +4dBm/33 kOhms, on detachable terminal blocks |
| Outputs | (5) x (8) composite video 1Vpp/75 Ohms and S/PDIF digital audio or S-video 1Vpp/75 Ohms (Y), 0.3Vpp/75 Ohms (C); and component video 1Vpp/0.7Vpp/75 Ohms on BNC connectors (8) balanced stereo audio, +4dBm/150 kOhms, on detachable terminal blocks |
| Performance | Maximum Output Level: Video: 2.8Vpp Audio: 24Vpp Bandwidth (-3dB): Video: 300MHz, fully loaded Audio: 100kHz Signal-to-Noise Ratio: Video: 74dB Audio: 84dB unweighted, (1Vpp) Crosstalk (all hostile): Video: <-50dB @ 5MHz Audio THD: 0.025% (1V, 1kHz) |
| Controls | Manual RS-232 RS-485 Ethernet |
| Power | 100 to 240VAC, 50/60Hz, 23VA |
| Dimensions (HxWxD) | 5.25 x 19 x 7" |
| Weight | 12.2 lbs (5.5kg) |
