Kramer SD-7588 8x8 SDI Video Matrix Switcher - BNC, Sync Capable, RS-232, Rackmountable

The Comprehensive SD-7588 is an 8x8 SDI Video Matrix Switcher; it accepts 8 inputs on BNC connectors and has 8 outputs. Any input can be assigned to any output simultaneously. This unit features large LED displays allowing the user to see input allocation.

True Matrix A true matrix mean that any input can be assigned to any or all outputs simultaneously. Standards This device can pass either Analog or SDI video signals; it passes standards such as.

• 4fsc PAL
• 4fsc NTSC
• 4:2:2(525/625)
• 360 Mb/s widescreen (525/625)

  This unit does not convert from analog to digital and was designed for SDI video even though it uses an analog signal for timing reference.

Universal Power This unit will operate from worldwide power, accepting 85 to 264 VAC @ 47 to 440 Hz. Vertical Interval Glitch free switching is possible when sources are referenced to the same signals as the switcher. Memory 15 memory presets can be accessed for quick control over frequently used configurations.
