Modem quang Olink E1 SM/SC 20 km FOM-E1

  Provides conversion from ITU-T G.703 E1 interface to 10/100Base-T Ethernet interface

  Ethernet interface supports half/full duplex auto negotiation, support VLAN

  E1 support N*64k （N=1-32）rates or full 2M

  Based on self –copyright IC

  Have pseudo random code test function, easy for the installation and maintenance

  Support 120Ω/balance and 75Ω/unbalance impedance

   Have Ethernet monitor self-reset function

  LED indicator can monitor the remote device from local device

Specification:

>>  E1 interface

      Standard: E1 interface compatible with G.703 standard.

      Coding:  HDB3

      Impedance: 75Ω (unbalance), 120Ω (balance)

      Connector:  BNC (75Ω), RJ45 (120Ω)

      Jitter Performance: According to G.742 and G.823

      Clock: internal clock, line clock.

>>  10M/100M Base-T

       Interface Rate 10/100Mbps

       MAC address capability 4096

       Interface character match IEEE802.3, IEEE802.1Q (VLAN)

Power Supply :AC 100V -240V  50-60HZ ,DC 5V,1A

Operating Temperature: 0° C to + 50°C

Storage Temperature:  - 40° C to + 75°C

Humidity: 5%-95%  Non-Condensing

Order Information

Part No	Description of product
OLINK CON02T	E1 to LAN protocol converter
