Leadtek NVIDIA Quadro FX 5000 (NVIDIA Quadro FX 5000, 2.5GB, 320-bit GDDR5 PCI Express 2.0)

Next-Generation NVIDIA® CUDA™ Architecture
Breakthrough NVIDIA CUDA parallel computing architecture, code named Fermi, tightly integrates advanced visualization and compute features delivering performance that greatly accelerates professional workflows.

NVIDIA® Parallel DataCache™
Supports a true cache hierarchy combined with on-chip shared memory. L1 and L2 caches drive exceptional throughput, accelerating features such as real-time ray tracing, physics and texture filtering.

Large Frame Buffers with Ultra-Fast Bandwidth
Large GPU memory with fast bandwidth for display of complex models and scenes, as well as computation of large datasets.

Fast 64-Bit Floating Point Precision
Industry’s fastest double precision floating point performance enabling accurate results on mission-critical applications, including computer-aided-design, finite element analysis to computational fluid dynamics.

Error Correcting Codes (ECC) Memory
Meets strict requirements for mission critical applications with uncompromised computing accuracy and reliability for workstations. Offers protection of data in memory to enhance application data integrity.

NVIDIA GigaThread™ Engine
Provides up to 10x faster context switching compared to previous generation architectures, concurrent kernel execution, and improved thread block scheduling

Dual Copy Engines
Enables the highest rates of parallel data processing and concurrent throughput between the GPU and host, accelerating techniques such as ray tracing, color grading and physical simulation

NVIDIA® Scalable Geometry Engine™
Dramatically improves geometry performance across a broad range of CAD, DCC and medical applications, enabling you to work interactively with models and scenes that are an order of magnitude more complex than ever before.

Fast 3D Texture Transfer
Fast transfer and manipulation of 3D textures resulting in more interactive visualization of large volumetric datasets.

Hardware 3D Window Clipping
Hardware accelerated clip regions (data transfer mechanism between a window and the frame buffer) improve overall graphics performance by increasing transfer speed between color buffer and frame buffer.

Unified Driver Architecture (UDA)
The NVIDIA UDA guarantees forward and backward compatibility with software drivers. Simplifies upgrading to a new solution because all Quadro products work with the same driver software.

Image Quality

 Full-Scene Antialiasing (FSAA)
Up to 128X FSAA dramatically reduces visual aliasing artifacts or “jaggies,” resulting in unparalleled image quality and highly realistic scenes.

GPU Tessellation with Shader Model 5.0
Quadro Tessellation Engines automatically generate finely detailed geometry, for cinematic quality environments and scenes, without sacrificing performance.

16K Texture and Render Processing
The ability to texture from and render to 16K x 16K surfaces.  Beneficial for applications that demand the highest resolution and quality image processing.

NVIDIA High Precision High Dynamic Range (HDR) Technology
Sets new standards for image clarity and quality through floating point capabilities in shading, filtering, texturing, and blending. Enables unprecedented rendered image quality for visual effects processing.

Display Features

High-Quality Display Connectors
Attaches to ultra-high-resolution panels producing phenomenal photorealistic image quality from a range of display connectors. Through the GPU support for two active connectors including, dual-link DVI-I with up to 3840 x 2400 @ 24Hz, DisplayPort with up to up to 2560 x 1600 @ 60Hz, or HDMI from a cable.

30-Bit Color Fidelity
30-bit color fidelity (10-bits per color) enables billions rather than millions of color variations for rich, vivid image quality with the broadest dynamic range.

NVIDIA® Quadro® Digital Video Pipeline
Industry’s only GPU-accelerated solution for real-time acquisition, processing, and delivery of high-resolution SDI video, across traditional and now 3D video broadcast environments. Supports uncompressed 8-,10-,12-bit SDI via optional Quadro SDI Capture and Quadro SDI Output cards.

NVIDIA® Quadro® G-Sync Solution
The Quadro G-Sync option card is an advanced solution that ensures frame synchronization between GPUs and provides a way to synchronize to an external source (also known as house sync). G-Sync allows advanced visualization systems to utilize many projectors or displays in unison delivering unprecedented levels of realism and betters ways to collaborate.

NVIDIA® 3D Vision Pro™ Stereoscopic Solution
Advanced active shutter glasses deliver crystal-clear stereoscopic 3D visualization for the most immersive experience. RF technology enables a range of environments ranging from collobrative work spaces to theaters. 3D Vision Pro solution sold separately.

OpenGL Quad Buffered Stereo Support
OpenGL Quad Buffered Stereo offers professional applications the capability of smooth and immersive 3D Stereo experience.

Professional 3D Stereo Synchronization
Enables robust control of stereo effect through a dedicated 3-pin mini-din connection between the graphics card and 3D stereo hardware.

Software Support

Programming the CUDA Parallel Computing Architecture
General purpose GPU computing using standard programming languages like C/C++ and Fortran, and emerging APIs such as OpenCL and Direct Compute.    This broad adoption of CUDA is accelerating techniques like ray tracing, video and image processing, and computation fluid dynamics.

Cg Programming
Programmable GPU leverages Cg high-level, open-standard shading language to enable the creation and integration of real-time photorealistic effects into 3D models, scenes and designs.

Microsoft® Windows® 7 Support
Take advantage of all the new and compelling features included with Windows 7, delivering unprecedented application performance, advanced visual realism, and premium reliability with superior application compatibility on mobile and desktop workstations.

Shader Model 5.0 Programmability
Infinite length vertex programs and dynamic flow control remove the previous limits on OpenGL and DirectX shader programs, delivering sophisticated effects never before imagined.

NVIDIA Graphics API Extensions
NVIDIA provides a set of extensions to standard graphics APIs for Linux and Windows, enabling applications to take maximum advantage of state-of-the-art GPU capabilities.

NVIDIA® Application Acceleration Engines Support
Supercharge application performance and capabilities with highly optimized software modules, including SceniX™ and OptiX™ for advanced creative and investigative possibilities.

Industry Standard

Compatible with Industry Standard Architectures
Compatible with Microsoft and Linux operating systems, as well as Intel and AMD x86 32- and 64-bit microprocessor architectures.

Ultra-Quiet Design
Acoustics lower than 28db for an ultra-quiet desktop environment.

NVIDIA® SLI® Multi-GPU Technology

NVIDIA® SLI® Technology
NVIDIA SLI technology leverages multiple GPUs to dynamically scale graphics performance, enhance image quality, expand display real estate and assemble a fully virtualized system.  Available on Quadro SLI certified platforms only.

NVIDIA® SLI® Multi-OS
NVIDIA SLI Multi OS allows a user to run multiple Windows or Linux workstation applications from a single system, with each Operating System directly assigned to a Quadro graphics solution.  Only available on SLI Multi-OS certified platforms.

NVIDIA® SLI® Mosaic Technology
NVIDIA SLI Mosaic Technology enables transparent scaling of any application, tear-free across up to four display channels, including support for 4K projection, while delivering full performance from a single SLI certified workstation. Available on Quadro SLI certified platforms only.
