| SDI Video Input |
|
2 x 10 bit SD, HD, 3Gb/s HD and 2K switchable. Usable as Dual Link HD-SDI for 4:2:2 or 4:4:4 connection or 3 Gb/s for HD-SDI 4:4:4 or 2K. |
| SDI Video Output |
|
2 x 10 bit SD, HD, 3Gb/s HD and 2K switchable. Usable as Dual Link HD-SDI for 4:2:2 or 4:4:4 connection or 3 Gb/s for HD-SDI 4:4:4 or 2K. |
| Analog Video Input |
|
Component YUV, NTSC, PAL and S-Video switchable between SD and HD in Component. |
| Analog Video Output |
|
Component YUV, NTSC, PAL and S-Video switchable between SD and HD in Component. |
| HDMI Video Input |
|
Direct HDMI connection supports HDMI capture from HDMI compatible cameras, set top boxes, decks and video games. |
| HDMI Video Output |
|
Direct HDMI connection supports HDMI digital compatible displays, such as a TV or video projector. Includes both audio and video. |
| Analog Audio Input |
|
4 Channels of professional balanced XLR analog audio. |
| Analog Audio Output |
|
4 Channels of professional balanced XLR analog audio.
2 Channels of unbalanced RCA analog audio for monitoring. |
| AES/EBU Audio Input |
|
6 x inputs on XLR connectors for 12 audio channels. Sample rate converted. |
| AES/EBU Audio Output |
|
6 x outputs on XLR connectors for 12 audio channels. |
| SDI Audio Input |
|
16 Channels in HD and 2K capture and playback mode. 8 Channels supported in SD.
16 Channels de-embedding supported from SDI input in converter mode. |
| SDI Audio Output |
|
16 Channels in HD and 2K capture and playback mode. 8 Channels supported in SD.
16 Channels embedding supported to SDI output in converter mode. |
| HDMI Audio Input |
|
2 Channels |
| HDMI Audio Output |
|
2 Channels |
| Audio Playback Support |
|
16 Channels in HD and 2K, 8 channels in standard definition. |
| Audio Capture Support |
|
16 Channels in HD and 2K, 8 channels in standard definition. |
| Multi Rate Support |
|
SDI and component analog video connections are switchable between standard definition and high definition. SDI switches between 270 Mb/s standard definition SDI, 1.5 Gb/s HD-SDI and 3 Gb/s HD and 2K SDI. |
| HDMI Configuration |
|
HDMI automatically configures to connected display. |
| HDMI Resolution |
|
Pixel for pixel HD resolution input to connected device. |
| HDMI Color Precision |
|
4:2:2 10 bit |
| 2K Film Support |
|
2048 x 1556 at 23.98fps, 24fps and 25fps capture and playback via SDI. |
| Sync Input |
|
Blackburst in SD or TriSync HD. |
| Device Control |
|
Sony™ compatible RS422 deck control port.
Serial ports TxRx direction-reversible under software control. |
| Supported Analog Formats |
|
525 NTSC, 625 PAL, 720HD and 1080HD switchable. |
| Supported SDI Formats |
|
525 NTSC, 625 PAL, 720HD, 1080HD and 2K 2048 x 1556 switchable. |
