USB to CAN Converter, ICP DAS Modul I-7565

I-7565 is a cost-efficient device for coupling the CAN-bus to the PC using the standard USB interface. The I-7565 Utility tool can be used to configure the operation conditions between the CAN and USB port communications.

• CAN (Controller Area Network)
  • Serial bus system suited to support intelligent industry device networks and build smart automatic control systems. The I-7565 is a cost-efficient device for coupling the CAN-bus to the PC using the standard USB interface. USB interfaces are now standard in PC's and are supported by the MS-Windows 98, Me, 2000 and XP operating systems.
  • I-7565 supports hot plug and play. The PC automatically loads the relevant device driver.
  • The following illustration shows the application architecture for I-7565 modules. The PC can be the CAN host, monitor or HMI to access/control the CAN device through the CAN network by the I-7565 Converter.
  • This module let you to communicate with CAN devices easily from PC with USB interface.
• 3000V isolation on CAN side
  • The CAN port of I-7565 has 3000V isolation.
  • This isolation can protect the local devices from the damage signal coming from CAN network.
• Watchdog inside
  • The I-7530 Watchdog is a hardware reset circuit to monitor the I-7565’s operation status.
  • In harsh or noisy environments, many devices are disrupted by the external signals.
  • The circuitry in I-7565 allows it to work continuously despite the harsh environment.
• Power and Error Indicator Display
  • The power indicator can help user to check whether the I-7565 is standby or transmitting/receiving messages.
  • The Error indicator is turned on when errors occur in the I-7565
• Applications
  • Factory Automation
  • Building Automation
  • Home Automation
  • Control System
  • Monitor System
  • Vehicle Automation

• Features
  • RoHs Design
  • Fully compliant with USB 1.1/2.0(Full Speed)
  • Power over USB: no external power is required
  • 20 Mhz Microprocessor inside
  • 82C250 CAN transceiver
  • Built-in converter firmware
  • Transmission speeds up to 1M bps for CAN and 921.6K bps for USB
  • Software configurable CAN and USB Communication Parameters
  • Maximum transmission distances over 1000m (follow CAN specification)
  • Supports both CAN 2.0A and CAN 2.0B
  • Built-in jumper to select 120Ω terminal resister
  • Mounts easily on DIN-rail
  • Power, data flow and error indicators for CAN and USB
  • Has Watchdog inside
  • Windows 98/ME/2000/XP drivers supported
  • Linux drivers supported
  • Free DLL for VC++, VB, and BCB
• I-7565 Utility
  • CAN bus Baud rate configuration
  • CAN acceptance filter configuration
  • CAN2.0A or 2.0B specific selection
  • Checksum and Error Response settings
  • Easy test to transmit/receive CAN messages

• Receive Buffer: 250 fps (standard frames per second)
• USB Type B Interface Connector
• CAN D-Sub, 9-pin Interface Connector
• Isolation voltage: Over 1000m Suggested
• Accessories: One USB Type A to Type B cable
• Dimensions: 123mm x 72mm x 33mm
• Operation Temperature:-25 to + 75
• Storage Temperature: -40 to +80
• Communication speed:
  • 921.6K bps fixed for USB
  • 1M bps max for CAN
