Thermaltake SMART Modular 650W Active PFC (SP-650MPCBEU)

Tính năng

- Complies with latest ATX 12V V2.3 Standard for utmost reliability and compatibility
- High current single +12V rail for best compatibility.
- Active PFC to improve energy efficiency and provide reliable power.
- Ultra-quiet 120mm cooling fan delivers excellent airflow.
- Extra long EPS/ATX 12V 4+4pin CPU cable support full tower chassis.
- Intel & AMD CPU compliant.
- Nvidia & ATI/AMD graphic card compatible.
- Dimension (W/H/D): 150mm x 85.1mm x 141mm.
- High reliability: MTBF>100,000 hours.
- Built-in industry grade protections: Over Voltage, Over Power and Short-Circuit protection
- Safety / EMI Approvals: TUV, CE, GOST

---

Technology Features

	Ultra-quiet 120mm cooling fan delivers excellent airflow.   Black coating design, the suitable power supply for your stylish black coating chassis.
	4+4-Pin EPS/ATX connector enables support for latest Intel and AMD processors today.

---

Fan Speed & Noise Level

---

Output Specification

AC INPUT	Input Voltage: 230Vac                                                                      Input Current: 6A Frequency: 50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5Vsb
Max Output Current	24A	30A	48A	0.5A	3A
Max Output Power	150W		576W	6W	15W
The +3.3V & +5V & +12V combined output power shall not exceed 680W.

---

Total Protection

Voltage Source	Over Voltage Protection
	Protection Point
+3.3V	4.1 Vmax.
+5V	6.5 Vmax.
+12V	14.5 Vmax.
Short Circuit Protection: An output short circuit is defined as any output impedance of less than 0.1 ohms. The power supply shall shut down and latch off for shorting the +3.3 VDC, +5 VDC, +12 VDC rails to return or any other rail.
Over Power Protection: The power supply shall be shut down and latch off, if the wattage of the power supply is higher from 130% to 160%。

---

Total Output Connector

Main Power (24 PIN) ATX 12V  (4+4PIN) PCI-E (6+2PIN) 4pin Peripheral Connector 4pin Floopy Connector 5pin S-ATA Connector 1 1 2 6 1 5

Connector Type Connectors & Cable length 20+4pin 1 x 20+4pin Main connector(500mm)    4+4pin EPS / ATX +12V  Power Connector 1 x EPS / ATX 4+4pin +12V Power Connector (550mm)      Molex & S-ATA & FDD Connector 2 x Molex & 1 x FDD connectors (500mm + 120mm + 120mm) 2 x Molex & 2 x S-ATA connectors (500mm + 120mm + 120mm +      120mm) 2 x Molex & 3 x S-ATA connectors (500mm + 120mm + 120mm + 120mm + 120mm) PCI-E Connector 2 x 6+2pin PCI-E Connectors (500mm + 150mm)



---
