Mô tả sản phẩm: Máy gấp thủy lực FINTEK VH-1010-6
|
MODEL
|
VH-1010-6
|
VH-1216-6
|
VH-4014-6
|
|
|
BENDING CAPACITY
|
BENDING LENGTH
|
3048mm(120")
|
3700mm(145")
|
3710mm(145")
|
|
MILD STEEL
|
3.5mm(10GA)
|
1.6mm(16GA)
|
2.0mm(14GA)
|
|
|
STAINLESS STEEL
|
2.5mm(12GA)
|
0.8mm(22GA)
|
1.2mm(18GA)
|
|
|
BENDING ANGLE
|
0-135°
|
0-135°
|
0-135°
|
|
|
BEAM ADJUSTMENT
|
25mm(1")
|
25mm(1")
|
25mm(1")
|
|
|
MIN REVERSE BEND
|
25mm(1")
|
16mm(1/2")
|
16mm(1/2")
|
|
|
MOTOR (HP)
|
5
|
3
|
5
|
|
|
PACKING SIZE (mm)
|
4000x1100x1750
|
4600x1160x1700
|
4600x1160x1700
|
|
|
PACKING WEIGHT
|
2480kgs
|
2800kgs
|
3700kgs
|
|
