Hệ thống đo lưu lượng dòng chảy DensFlow Flow Dungs

Sensor

Housing

Stainless Steel 1.4571, NW 10 ... 125 mm, flange EN 1092-1

Inner pipe

Ceramic

Protection category

IP 65 according EN 60 529/10.91

Environment temperature

Sensor pipe electronic:
- 20 ... + 60 °C
Sensor pipe:
- 20 ... + 80 °C (higher temperatures as option)

Max. working pressure

16 bar, optional 25 bar

Working frequency

100 kHz

Weight

Depending on the nominal diameter

Velocity range

1 ... 10 m/s

Accuracy

± 2 ... 5 % in the calibrated range range

Dimension

NW + 90 mm, L 500 mm

Transmitter

Power supply

110 / 240 V, 50 Hz, 24 V DC

Power consumption

20 W / 24 VA

Protection category

IP 65 to EN 60 529 / 10.91

Operating temperature

- 10... + 45 °C [14 ... 113 °F]

Dimensions

258 x 237 x 174 (W x H x D)

Weight

approx. 2.5 kg

Cable glands

3 x M 16 (4.5 - 10 mm Ø)

Terminal clamp wire size

0.2 - 2.5 mm² [AWG 24-14]

Current output signal

2 x 4 … 20 mA (0 … 20 mA), load < 500

Alarm output - Error output

Relay with toggle switch - max. 250 V AC, 1 A

Data backup

Flash memory

Impulse output

Open Collector - max. 30 V, 20 mA

RS 485 interface

ModBus
