Mô tả sản phẩm: Alcatel-Lucent OmniSwitch 6850E Non-PoE module OS6850E48XD
The new Alcatel-Lucent OmniSwitch™ 6850E Stackable LAN Switch (SLS) is the latest advanced stackable gigabit Ethernet switch in the OmniSwitch family of products. The OmniSwitch 6850E is available in 24-and 48-port configurations and provides wire-rate layer-2 and layer-3 switching simultaneously for IPv4 and IPv6. The OmniSwitch 6850E provides fine grained controls for quality of service (QoS) and for security including network access control (NAC). It offers full support for 802.3at-compliant power over Ethernet (PoE) and stacks with the existing OminSwitch 6850 family, allowing for smooth expansion of existing installations where PoE+ or SFP+ is needed.
These versatile LAN switches can be positioned at the edge of mid to large size enterprise networks, at the aggregation layer, small enterprise core, and are suitable as advanced CPE in Ethernet access metro deployments.
Description
OS6850E-48X: Gigabit Ethernet L3 fixed configuration chassis in a 1U form factor with 46 RJ-45 10/100/1000 BaseT ports, 2 combo ports (10/100/1000 BaseT or 1000 BaseX), 2 SFP+ 10GigE ports, and 2 CX-4 ports. The 2 CX-4 ports can be used as stacking ports or as connectors for the OS6-XNI-U2 that supports 2 SFP+ 10GigE ports. The bundle includes a 120W DC power supply with power shelf and country specific power cord,user manuals access card, rack mounts, and RJ-45 to DB-9 adaptor.
Features
Versatile features and models offering:
- Gigabit and 10 Gigabit interfaces
- IEEE 802.3af and 802.3at compliant PoE
- Optional 10GigE plug-in module delivers additional 2 10 Gigabit SFP+ ports
Support for 10GigE SFP+ LRM optics
Low power consumption, full support for 802.3at PoE+ providing up to 30W of PoE per port
Wire-rate performance for switching and routing at 10G and gigabit speeds. Advanced services are incorporated in the operating system; for example, QoS, access control lists (ACLs), L2/L3, VLAN stacking, and IPv6
Redundancy at all levels including power supplies, software and hot-swappable Small Form Factor Pluggable (SFP) modules
Extensive security features for network access control (NAC), policy enforcement and attack containment
Hardware-based virtual routing and forwarding (VRF) support
Ready for Metro Ethernet access: VLAN stacking, multicast switching, Dynamic Host Configuration Protocol (DHCP) snooping/option 82, ITU-T Y.1731, IEEE 802.1ag
These versatile LAN switches can be positioned at the edge of mid to large size enterprise networks, at the aggregation layer, small enterprise core, and are suitable as advanced CPE in Ethernet access metro deployments.
Description
OS6850E-48X: Gigabit Ethernet L3 fixed configuration chassis in a 1U form factor with 46 RJ-45 10/100/1000 BaseT ports, 2 combo ports (10/100/1000 BaseT or 1000 BaseX), 2 SFP+ 10GigE ports, and 2 CX-4 ports. The 2 CX-4 ports can be used as stacking ports or as connectors for the OS6-XNI-U2 that supports 2 SFP+ 10GigE ports. The bundle includes a 120W DC power supply with power shelf and country specific power cord,user manuals access card, rack mounts, and RJ-45 to DB-9 adaptor.
Features
Versatile features and models offering:
- Gigabit and 10 Gigabit interfaces
- IEEE 802.3af and 802.3at compliant PoE
- Optional 10GigE plug-in module delivers additional 2 10 Gigabit SFP+ ports
Support for 10GigE SFP+ LRM optics
Low power consumption, full support for 802.3at PoE+ providing up to 30W of PoE per port
Wire-rate performance for switching and routing at 10G and gigabit speeds. Advanced services are incorporated in the operating system; for example, QoS, access control lists (ACLs), L2/L3, VLAN stacking, and IPv6
Redundancy at all levels including power supplies, software and hot-swappable Small Form Factor Pluggable (SFP) modules
Extensive security features for network access control (NAC), policy enforcement and attack containment
Hardware-based virtual routing and forwarding (VRF) support
Ready for Metro Ethernet access: VLAN stacking, multicast switching, Dynamic Host Configuration Protocol (DHCP) snooping/option 82, ITU-T Y.1731, IEEE 802.1ag
