Đầu báo cháy Cực tím/Hồng ngoại cỡ nhỏ Spectrex 20/20ML

The low cost 20/20ML UV/IR Flame Detector has a compact, lightweight but rugged design for general purpose (non-Ex approved) areas. It detects hydrocarbon fire at distances up to 50 ft (15 m).

The 20/20ML provides a combination of UV and IR sensors and can detect hydrocarbon-based fuel and gas fires, hydroxyl and hydrogen fires, as well as metal and inorganic fires. The UV sensor incorporates a special logic circuit that helps prevent false alarms caused by solar radiation. Simultaneous detection of radiant energy in both the UV and IR sensors triggers an alarm signal.



Features

• UV/IR Dual-Sensor
• High-Speed Response
• 50 msec Response to Saturated Signal
• Large Field of View (100° horizontal/vertical)
• User Programmable Functions Configurable via software from a PC or handheld device
• Immune to False Alarms (solar blind)
• Automatic and Manual Built-In-Test (BIT)
• Standard 4-wire Connection
• 4-20mA source (3-4 wires) configuration
• RS-485 Modbus Compatible
• MTBF Minimum 100,000 Hours
• 3-Year Warranty
