Bộ điều khiển chiều cao mỏ Wuxi Longteng CHC-200D

This is our best-seller from the start, monthly sale 350--500 sets.

1. Analog circuit instead of SMD Tech on our THC, PWM driving mode, ensuring high reliability of THC.

2. Adopt circuit-broken protection, it would protect torch head from crashing on workpiece during the situation of HF disconnected, open circuit, short circuit.

3. Full-closed design, waterproof, dustproof, shockproof.

4. It adopts a method of modularization design, which is convenient for installation, commissioning and maintenance.

5. Unparalleled circuit-protection design greatly strengthens ability of anti-jamming. Resister and capacitor absorb circuit is adopted on power supply, preventing the interference of surge voltage and harmonic wave to THC effectively. Pressure sensitive circuit protection is adopted, avoiding the damage of over-voltage, and mis-connecting of power supply. Time-varying circuit is adopted, avoiding the damage of over-high voltage brought by work piece under sensing (protection voltage>91v). Self-recovery circuit is adopted on signal-collecting part, at this part, the detecting circuit would break off if the current is over 1.3Ah.

6. Outside height setting, besides the HEIGHT button on operation panel, there’s a R39⊕at the back of control box, adjusting the height when the set height is not right.

Details

Full Name of Product	Capacitive Torch Height Controller
Driving Mode	PWM
Dimensions	L*W*H:155*104*50（mm）
Supply voltage	AC24V±10% 50Hz/60Hz
Lifting motor	DC24V DC motor
DC24V DC motor	1A~6A
Working temperature	Torch height controller: -10℃~60℃; high-frequency co-axial cable: -10℃~200℃; probe assembly: -10℃~350℃
Control Accuracy	±0.2mm
Control Range	Distance to workpiece surface: 1mm~20mm
Maximum output power	150W
High-frequency cable length	1000mm
Breaking circuit protection	HF high-frequency section
