ETHERNET FIBER MODEM

Model: MEO-100

Overview:

MEO-100, Net Bridge with fiber optic interface is a multifunction and high performance L2 switch which build in three port cross engine to realize the conversion between two Ethernet interface and E1 interface. The equipment supports the function used as Ethernet transceiver or Ethernet net bridge or fiber optic modem. As the extension of Ethernet, MEO-100 Net Bridge may realize Ethernet interconnection at low cost via the E1 channel provided by existing network.

Feature:



  • In accordance with G.703, G.704, G.736, G.823, IEEE 802.3u standard.

  • E1 interface framing or un-framing optional;

  • Ethernet interface 10/100M, full/half duplex modes auto-negotiation;

  • Support one optic interface of E1.

  • MAC addresses self-learning and addresses filtering automatically.

  • Two architectures: stand alone and 19in rack mount architecture (16 interface converter modules can be inserted in the rack mount architecture);

  • Optional AC 220V or DC –48V input for bridge of both architectures.

  • Hot rear up of double power supplies is provided for the Bridge of rack mount architecture, assuring high reliability

Specification:



Optical Port

Rate

2.048Mbit/s

Coding

CMI

Connector

SC

Protocol

G.703; G.704;

Jitter tolerance

G.823

Ethernet Port

Rate

10/100M

Connector

RJ45

Standard

IEEE 802.3

Operation Environments

Power supply

220VAC/-48VDC;

Operational temperature

0oC ~ 50 oC

Storage temperature

-20 oC ~ 80 oC

Humidity

95% (no conden-sation)

Power dissipation

3W

Size

190x154x37 (mm)

  Topography:



Indicator light:



POWER

Always lights after starting up

LINK

lights When the Electric Ethernet linked normally

RX

Data reception. Flickers when data receives

TX

Data transmission.

LOF

Alarm indicator lamp for input signal out-of-frame in E1 line. Constantly lightening indicates the local; flash with opposite device.

LOS

E1 link interruption alarm

AIS

Always lights afterreceiving an alarm indication signal

LOOP

Test. Always light ỏ flickers in testing.

PTOK

Circuit pseudo-random sequence test success.

Order information:



The model of Protocol  Converter

MEO-100

10/100M Ethernet-E1 fiber interface, SC, 20km, AC or DC

MEL-100FB

FE1-10/100 BASE-TX bridge, N*64K, 75ohm &120ohm, AC or DC

MEL-200F/400F

FE1-2/4*10/100 BASE-TX bridge, N*64K, 75ohm & 120ohm, AC or DC

MVL-100

V.35-10/100 BASE-TX bridge, N*64K, AC or DC

MEV-LR

FE1-V.35 & Eth & RS232 bridge, N*64K, 75ohm & 120ohm, AC or DC

MEV-4LR

FE1-V.35 & 4Eth & RS232 bridge, N*64K, 75ohm & 120ohm, AC or DC

MER-132

E1-RS232 bridge, 2.048M,75ohm & 120ohm, AC or DC

MER-132F

FE1-RS232 bridge, N*64K, 75ohm & 120ohm, AC or DC

MEV-135F

FE1-V.35 bridge, N*64K, 75ohm & 120ohm, AC or DC

MEL-40/80/160

4/8/16E1 to 10/100-BASE-TX bridge, 75ohm or 120ohm, AC or DC

MEL-40B/80B

4/8E1 to 4*10/100-BASE-TX  bridge, 75ohm or 120ohm, AC or DC

MEO-101

FE1-Optic 100 Base-FX Bridge, N*64K, 75ohm & 120ohm, 20km, AC or DC.

MEO-401

4E1-Optic 100  Base-FX Bridge, 75ohm & 120ohm, 20km, AC or DC

MEO-801

8E1-Optic 100  Base-FX Bridge, 75ohm or 120ohm, 20km, AC or DC

ME-16

16 slots modular chassis (one NMS modular optional), all kinks of modular between E1/V35/Eth/Fiber is optional,4.5U, 19 inch, 1+1 power backup, AC or DC.

If you have other requirements of connect or longer distance, please get in touch with us
