Mô tả sản phẩm: Maxsecure M2371SV-4AH
| Camera Model | M2371SV-4AH |
| Lens | 6-22mm Manual Zoom Lens (2MP) |
| Lens Mounting | CS Mount |
| Auto Iris | - |
| IR Lamp | ￠42X4 PCS IR LED Array |
| Mechanical IR Cut Filter | Yes |
| Smart IR | No |
| IR Distance | 80 Meter |
| Camera Series Parameter ______________________________________________ | |
| Camera Series | SONY SV Series |
| Image Sensor | 1/3" SONY EXview HAD CCD II |
| Image Format | 760P/960H |
| Digital Signal Processor-DSP | SONY CXD4129GG |
| Horizontal Resolution | 720TVL |
| Minimum Illumination | 0.001 Lux(IR LEDs on at 2 Lux) |
| Pixel | 976(H)X582(V) |
| Signal-to-Noise Ratio | >55dB (AGC off) |
| Scanning System | 2:1 Interlace |
| Video Output | Composite Signal (1.0Vp-p, 75Ω) |
| Function & Features __________________________________________________ | |
| OSD - On Screen Display | YES/UTC |
| White balance-WB | ATW / AWB / PUSH LOCK / MANUAL / 3200K / 6300K / ANTI CR |
| Auto Gain Control-AGC | Auto |
| High Light Compensation-HLC | YES |
| Back Light Compensation-BLC | YES |
| Electronic Shutter | Auto/Manual |
| Day/Night mode | COLOR/ B &W/ AUTO/ DAY & NIGHT SCHEDULE/ EXT |
| Mirror | Yes |
| Digital Zoom | E-zoom |
| Sharpness | Auto/Manual |
| Wide Dynamic Range-WDR | ATR-EX / WDR/ FOG |
| Digital Slow Shutter-DSS | YES |
| Noise Reduction-NR | 2D/ 3D-DNR |
| Motion Detection-MD | YES |
| Privacy Zone Masking-MASK | YES |
| Sens-Up | Auto (Limit x2-x512) |
| Camera Name Display | YES |
| Image Freeze function | |
| IR-Smart | - |
| D.I.S - Digital Image Stabilizer | YES |
| Defrog | YES |
| Lens Shading | YES |
| Power & Operation ____________________________________________________ | |
| Voltage input | 12VDC |
| Power Consumption | 500mA ± 5% |
| Operating temperature / humidity | -10°C ~ 50°C / RH95% Max |
| Housing and Bracket __________________________________________________ | |
| Mounting bracket | 2 Axis Wall Bracket |
| Casing Construction | Outstanding Durability Aluminium Box Body |
| Lens Cover | Anti IR Reflet Front Independent Glasses Design |
| IP rating | IP66 Weatherproof Outdoor Standard |
| Weight | 2.5kg |
| Sized | 400(W) x 152(H) x 175(D) mm |
