Fan Filter Unit Điều Khiển 5 Cấp Độ, Ffu, Ffu 5 Cấp

Item

Specification

Remarks

Module Size

600 * 1200 mm

Module size can be designed according to customers requirements besides standard module.

900 * 1200 mm

750 * 1500 mm

1200 * 1200 mm

Air Flow Velocity

1Φ

0.4/0.35/0.3/0,25/0,2m/s

1Φ

0,25 (lo speed) – 0,45 (hi speed) m/s

Main Filter

HEPA

0.3μm Over 99.99%

HEPA:High Efficiency Particulate Air

ULPA

0.1μm Over 99.9995%

ULPA:Ultra Penetration Air

0.1μm Over 99.99995%

0.1μm Over 99.999995%

PTFE

0.1μm Over 99.9995%

PTFE:Poly Tetra Fluoro Ethylene

Main Body

Standard

Stainless Steel (SUS430)

Option

Galvanized Sheet Iron

AL-ZN Alloy Sheet

Coating Sheet Iron

Power Supply

Standard

3Φ 220V 60Hz， 1Φ 220V 50Hz，1Φ 220V 60Hz

Option

3Φ 380V 50Hz，3Φ 380V 60Hz，3Φ 208V 50Hz，3Φ 208V 60Hz

Option

• Pre-filter
• Power plug and cable
• Duct flange for suction air

As each FFU has over current relay unit, the capacity of switchboard can be applied up on request.
