| Process Fluid: | Display: |
| Liquid, Gas of Vapor | 5 Digits programmable & 0-100% Bargraph |
| Application: | Display Unit: |
| Differential Pressure, Gauge Pressure, | Standard 22 engineering unit |
| Absolute Pressure | 5 Digits programmable for special unit |
| Measuring Range: | Keyboard: |
| 0 - 0.125 Kpa ~ 0 - 1.5 Kpa ( Minimum ) | 3 keys from internal for Programming |
| 0 - 4.0 Mpa ~ 0 - 25.0 Mpa ( Maximum ) | and output setting |
| Turn Down Ratio: | Current Output: |
| 1 : 100 | 4 - 20 mA 2 wires with Hart Signal |
| Accuracy: | Load |
| +/- 0.075% of span | Rohm=(Vdc-9)*50 |
| Stability: | Power Supply: |
| +/-0.15% of URL for 2 years | 9 - 36 VDC |
| Working Temperature: | Damping Adjustment: |
| -25 to +95oC | 0 - 32 Second |
| Max. Pressure: | Response Time: |
| 40 Mpa | 200 mS |
| Material: | Mounting: |
| Flange/Adapters | Bracket on 2" Pipe |
| Stainless Steel 304 / Stainless Steel 316 | Humidity Limits: |
| Drains/Vents | 0 to 100% Relative Humidity |
| Stainless Steel 304 / Stainless Steel 316 | Turn on Time: |
| Diaphragms | 2 Seconds with minimum damping |
| Stainless Steel 316L / Hastelloy B / | Zero calibration: |
| Hastelloy C / Monel / Tantalum | Automatic zero calibration by press button |
| Wetted O-Rings | Electrical Connections: |
| Buna N / Viton / PTFE | M20 Conduit Threads / 1/2" NPT( Female ) |
| Bolts & Nuts | Temperature Effect: |
| Carbon Steel / Stainless Steel 316 | +/-0.18% of span per 20 oC |
| Mounting Bracket | Vibration Effect: |
| Carbon steel / Stainless Steel 304 / 316 | +/-0.05% of URL per g to 200 Hz in any |
| Name / Tag Plate | axis |
| Stainless Steel 304 / Stainless Steel 316 | EMI/RFI Effect: |
| Converter Housing | Follow SAMA PMC 33.1 from 20 to 1000 |
| Low copper cast aluminum alloy with | MHz and for field strengths up to 30 V/m |
| polyurethane, light blue paint | Process connections: |
| Fill Fluid | 1/4 - 18 NPT |
| Silicone / Fluorine Oil | 1/2 - 14 NPT( with Adapter ) |
| Enclosure: | Ambient Temperature: |
| IP67 ( Standard ) | -25 to +80 oC |
| Intrinsically Safe EEx ia IIC T5 ( Standard ) | Dimensions: |
| Explosion proof Ex D IIB T5 | 102 mm ( W ) * 188 mm ( H ) * 130 mm (D) |
| Weight: | |
| 3.5 Kg |
