Mô tả sản phẩm: Camera Uniview IPC141E-X22-IN
Specifications
|
Camera |
IPC141E-X22-IN |
IPC141E-X22-NL-IN |
|
Sensor |
1/3", 1.3Megapixel, progressive scan, low illumination CMOS |
|
|
Lens |
4.7 ~ 103.4 mm (22x optical zoom) |
|
|
Angle of View (H) |
||
|
Aperture |
Auto/Manual; F1.6 ~ F3.2 |
|
|
Shutter |
Auto/Manual; shutter time: 1/6 s ~ 1/10000 s |
|
|
Minimum Illumination |
Color: 0.03 lux (F1.6, 50IRE) |
|
|
Day/Night |
IR-cut filter with auto switch (ICR) |
|
|
Video |
||
|
Maximum Resolution |
1280 × 960 |
|
|
Video Compression |
H.264 High Profile |
|
|
Frame Rate |
960P (1280*960) 30 fps; 720P (1280*720) 30 fps; D1 (720*576) 25 fps |
|
|
Video Streaming |
Triple, individually configurable streams |
|
|
OSD |
3 Groups of OSD：Time OSD，Name OSD(up to 8)，customized OSD |
|
|
Privacy Mask |
Up to 8 areas |
|
|
16 Patrol routes with 32 presets per route 4 Patrol modes with unlimited recording time |
||
|
Home Position |
Support |
|
|
Audio |
||
|
Audio Compression |
G.711 |
|
|
Two-way Talking |
Support |
|
|
Storage |
||
|
Edge Storage |
SD/SDHC, Up to 32 GB |
|
|
Back-end Storage |
Dual Direct-to-iSCSI data block storage |
|
|
Cache Post Recording |
Support |
|
|
Interface |
||
|
Audio I/O |
3.5 mm audio interface |
|
|
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
||
|
Output: impedance 600 Ω; amplitude 2 V [p-p] |
||
|
Alarm I/O |
2 alarm inputs and 1 alarm output |
|
|
Support for alarm-triggered actions |
||
|
Serial Port |
1 RS485 |
|
|
Network |
1 10M/100M Base-TX Ethernet |
1 100M Base-FX SFP |
|
Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
|
|
Power Supply |
12 V DC (2-pin phoenix connectors) |
|
|
General |
||
|
Power |
9 ~ 12 V DC, or PoE (IEEE802.3 af) |
|
|
Power consumption: 4.7 W |
||
|
Dimensions (L×W×H) |
126 × 50 × 69 mm (5.0” × 2.0” × 2.7”) |
|
|
Weight |
0.5 kg (1.1 lb) |
|
|
Operating Conditions |
–20°C ~ +60°C (-4°F ~ 140°F), Humidity ≤ 90% RH(non-condensing) |
|
