Mô tả sản phẩm: MODEM WIFI ADSL2 TP-LINK TD-W8960N 300MBPS
|
Software Specification
|
|
|
ADSL Features
|
Full-rate ANSI T1.413 Issue 2
|
|
ITU-T G.992.1 (G.dmt)
|
|
|
ITU-T G.992.2 (G.lite)
|
|
|
ITU-T G.994.1 (G.hs)
|
|
|
ITU-T G.992.3 (G.lite.bis)
|
|
|
ITU-T G.992.5
|
|
|
Max 6 kilometers
|
|
|
Data Rates
|
Downstream: Up to 24Mbps
|
|
Upstream: Up to 3.5Mbps (With Annex M enabled)
|
|
|
ATM Features
|
UNI 3.1，ATM Adaptation Layer Type 5-AAL5
|
|
Multiprotocol encapsulation over ATM (RFC 1483)
|
|
|
UBR, CBR, VBR-rt, VBR-nrt
|
|
|
Supports 8PVCs
|
|
|
PPP Features
|
PPP over ATM (RFC 2364)
|
|
PPP over Ethernet (RFC 2516)
|
|
|
Switching Features
|
IGMP snooping
|
|
IGMP multicast
|
|
|
IEEE 802.1d transparent learning bridging
|
|
|
Routing Features
|
Classical IP and ARP over ATM (RFC 1577/2225), MER, RIP V1/V2
|
|
Static Routing, IP, TCP, UDP, ARP
|
|
|
NAT, NAPT, DNS, DDNS, DHCP Server
|
|
|
UPnP, Virtual Server, DMZ, Port Trigger
|
|
|
SIP, H323 ALG
|
|
|
Wireless Features
|
Complies with IEEE802.11n(Draft2.0), IEEE 802.11g, IEEE802.11b
|
|
11n: Up to 300Mbps(dynamic)
|
|
|
Provides WPA/WPA2 and WPA-PSK/WPA2-PSK authentication
|
|
|
Provides 64/128bit WEP encryption security and wireless LAN ACL (Access Control List)
|
|
|
Max wireless transmit power: 19dbm
|
|
|
Antenna power: 3dbi
|
|
|
Frequency Range:2.4~2.4835GHz
|
|
|
Security
|
NAT
|
|
IP filterling
|
|
|
MAC filtering
|
|
|
Parental control
|
|
|
IPSec VPN
|
Support up to 10 IPSec VPN tunnels
|
|
VPN Pass Through
|
IPSec/PPTP/L2TP Pass-through
|
|
QoS
|
IP Type of service(ToS)
|
|
802.1p
|
|
|
Device Management
|
HTTP, Console
|
|
Administration and operation software (firmware) upgradable locally by web(HTTP), console(TFTP)
|
|
|
CWMP(TR-069)
|
|
|
Hardware Specification
|
|
|
Ports
|
4 10/100M LAN Ports(RJ45)
|
|
1 Line Port(RJ11)
|
|
|
LED Indicators
|
Power, Internet, ADSL, WLAN, LAN1~4,QSS
|
|
Dimensions (W*D*H)
|
7.9*5.5*1.1 in.(200*140*28 mm)
|
|
Environment
|
Operating Temperature: 0℃~40℃ (32℉~104℉)
|
|
Storage Temperature: -40℃~70℃ (-40℉~158℉)
|
|
|
Operating Humidity: 10%~90% non-condensing
|
|
|
Storage Humidity: 5%~90% non-condensing
|
|
